Mechanical Precision Guillotine Shear

Request a Quote

View All: http://accurlcnc.com/1-5-mechanical-guillotine-shearing-machine/294485/index.html

Whole Structure of Mechanical Precision Guillotine Shear

With totally European design, streamlined looking, this machine belongs to second generation of mechanical shear. Welded structure: the stress of the welded parts can be eliminated by vibration, so that the cutting is of high accuracy.
Different from the traditional driving method of mechanical shear, it's one of the most advanced miniature mechanical shear, and enjoys good reputation both at home and abroad.
The low cutting angle and the inclined shear direction reduce the warpage to a minimum. Blade clearance is easily set by a manually operated quick set device. It is an ideal precision machining machine for metal sheets.

Features

QH1D series enables high productivity with its ergonomic design.
Silent running, direct drive system with brake motor, low cost in energy consumption.
Treadle operating system suitable for both single and repetitive cutting cycles.
NC controlled back gauge (650mm stroke) by E10s which ensures a higher cutting accuracy.
The machine passed the European Union CE certification and ISO quality system certification.

Electrical System and Safety Interlock

Electrical components are imported from Germany, in accordance with international standards, featuring reliable safety, long life, and good anti-interference ability. A radiation unit is fitted in electrical cabinet.
Protective grill and the safety interlock ensure the operation safety. With a movable single-hand pedal switch, the machine is easy to operate.
Emergency stops and foot switch are installed on the machine for safety. The grill guard is standard, but the curtain is optional.

Specifications

Model (QH11D)	Unit	3.5×1250	3.2×1500	4×1600	3.2×2000	2 ×1800	2 ×2500	3.2×2500
Cutting Thickness	mm	3.5	3.2	4	3.2	2	2	3.2
Cutting Length	mm	1250	1500	1600	2000	1800	2500	2500
Cutting Angle		1°30′	1°30′	1°45′	1°45′	1°35′	1°45′	1°20′
Number of Stroke	mim-1	65	55	55	55	55	55	55
Back Gauge	mm	0-650	0-650	0-650	0-650	0-650	0-650	0-650
Height of Worktable	mm	800	800	800	800	800	800	800
Motor Power	Kw	5.5	5.5	7.5	7.5	5.5	7.5	7.5
Net Weight	Kg	1450	1650	2150	1800	1800	2080	2200
External Dimensions	Length	1860	2124	2650	2624	2250	3124	3124
	Width	2210	2210	2210	2210	2250	2210	2210
	Height	1180	1180	1250	1180	1250	1180	1180
Working Environment	1. Power : 380±10%,50HZ
	2. Ambient temperature: 5~40℃(working temperature)
	3. Ambient humidity: 20~80%RH
	4. Far from strong shaking and electromagnetism
	5. No harmful gas and no corrosive gas and dirt-free
	6. Conforms to the disposition of the machine directive (directive 89/392 CEE), and following amendments (directive 91/368/CEE, 93/44/CEE, 93/68/CEE);
	7. Conforms to the disposition of the following other directives: directive low voltage (73/23/CEE) and electromagnetic compatibility (89/336/CEE).
