Wireless Charging Coil Winding Machine
Request a Quote
Model: AM-FSRX-10
Featured with a tension feeder, the coil winding machine is specially designed for the winding of the wireless charging coil with different shapes. This machine features single layer winding, and Alpha winding is available upon request. The wire diameter ranges from 0.3 to 1.2mm. With a PLC control system, precise winding and counting is ensured. An emergency braking device with an alarm system provides great protection during the abnormal operation.
Technical Parameters
| Application | Wireless charging coil |
| Feeder | Tensioner |
| No. of spindles | 1 |
| Winding method | Alpha winding or single winding |
| Wire size | 0.3-1.2mm |
| Control system | PLC |
| Capacity | 280-380pcs/h(Alpha); 800-1000pcs/H(single) |
| Dimensions(mm) | 1000*700*1800mm(L*W*H) |
| Air supply | 0.4-0.6Mpa |
| Working environment | 0-50℃(No corrosive gas, harmful gas, flying dust, etc.） |
| Power supply | Single phase AC220V/50HZ |
| Power consumption | 3kw |
| Weight | 300kg |
