1500W Drive Motor, PMDC Brushed Motor ZD132A1

1500W Drive Motor, PMDC Brushed Motor ZD132A1
1500W Drive Motor, PMDC Brushed Motor ZD132A1
1500W Drive Motor, PMDC Brushed Motor ZD132A1
Request a Quote
Power
Your Motion

Application: electric moped, electric bike, electric scooter and so on.

Technical Specifications
Rated Power (W) 1500 1500
Rated Voltage(V) 24 36
No-load Current(A) ≤7.5 ≤5.0
No-load Revolution (RPM) 3500 3500
Rated Torque(N•m) 4.4 4.4
Rated Revolution (RPM) 3000 3000
Rated Current(A) ≤83.0 ≤55.5
Rated Efficiency (%) ≥75 ≥75
Working Cycle (min.) S2-60 S2-60
Insulation Class F F
Protection Level IP44 IP44
Gear Ratio / /
Length (mm) 200 200

Note: we can customize any brushed drive motors according to your requirements and working conditions.
