High Speed Planer

Request a Quote

View All: http://woodmachines-en.com/1-8-1-high-speed-planer.html

//Woodworking Machinery

Single-sided and double-sided planers for planing and sanding of wood

Woodworking Machinery

Planing spindle diameterØ125mm
Feeding speed0.1-30m/min
Machine dimensions (L×W×H)2600×1150×1800mm
Machine weight2260kg

The high speed planer is available in both single-side and double-side configurations, designed for fast and precise surface treatment of solid wood materials. It performs planing and sanding operations to produce smooth, even surfaces suitable for further processing or finishing. With a feed speed of up to 30 meters per minute, this planning machine is ideal for high-throughput production environments where speed and surface quality are equally critical.

Specifications

Mode	630mm Double-Sided Planer	850mm Double-Sided Planer
Planing spindle diameter	Ø125mm	Ø125mm
Max. working width	630mm	850mm
Workpiece thickness	110-450mm (customizable)	110-200mm (customizable)
Min. working thickness	5mm	3mm
Feeding speed	0.1-30m/min	0.1-30m/min
Main motor power	11kW×2pcs	15kW×2pcs
Feeding motor power	1.5kW×2pcs	3kW×2pcs
Lifting motor power	0.37kW×2pcs	0.37kW
Machine dimensions (L×W×H)	2600×1150×1800mm	2600×1400×1800mm
Machine weight	2260kg	2660kg
