TOP-330RGD Hot Stamping Machine
This product has been discontinued and removed from our shelves.
T0P-330RGD hot stamping machine possesses many excellent characteristics that the first generation of intermittent die cutting machine has. Based on it, it has been optimized in terms of details and operation experience. When it comes to performance and characteristics, the TOP-330RGD is superior to the TOP-300 hot stamp machine.
The entire stamping press is designed with a robust platform which includes rotary screen printing, rotary hot stamping, semi-rotary die cutting, sheeting, stacking and rewinding modules. The advanced central control system combined with servo drive system, user-friendly operation design and accurate reinsertion system provides you higher quality of the product and also makes production highly efficient.
1. 700mm diameter unwinding/rewinding design
2. Ultrasonic tension detection and closed-loop tension control system.
3. Brand-name web guiding system
4. Modular design, blank space reserved for functions upgrade in the future.
5. Servo drive system, much more stable and higher accuracy
| Max. Speed | 300cycles/min |
| Accuracy of Cutting | ±0.15mm |
| Foil Register Accuracy | ±0.2mm |
| Max. Printing Width | 320mm |
| Printing Girth | 55T-160T |
| Max. Die Cutting Area | 330mmx320mm (LxW) |
| Paper Width | 80mm-330mm |
| Max. Unwinding Dia. | 700mm for about 2000m materials |
| Max. Rewinding Dia. | 700mm for about 2000m materials |
| Magnetic Cylinder | 120Teeth l/8"CP (Standard) |
| Repeat Length of Die Cutting | 50mm-330mm |
| Motor Power | 10 KW |
| Rotary Stamping Heater | 4KW |
| Overall Dimension (LxWxH) | 3600mmxl 200mmx1500mm |
| Weight | 3000kg |
Unwinder Web Guide
1. Closed-loop tension control
2. Machine stops or decelerates when less paper is fed.
3. Automatically controlled web guider with ultrasonic system
Rotary Screen Press
1. Rotary screen press for medium and huge quantity order
2. Rotary screen guarantees the qualified foiling quality and higher efficiency.
Rotary Hot Stamping
1. Rotary hot stamping for medium and huge quantity order
2. Rotary hot stamping guarantees the qualified foiling quality and higher efficiency.
Semi-rotary Die Cutter
1. Independent servo driver works with mark sensor.
2. Both the magnetic and solid cylinders fit in semi-rotary and full rotary cutting.
