The TOP-330TWINS rotary die cutting machine with double stations is suitable for complex projects with adhesive labels. The die cutter can easily cut the first layer and release layer together. The two stations have a movable design which can be adjusted according to the plate length. This double station rotary die cutter functions in both rotary and semi-rotary modes.

Main technical parameter
Max Die Cutting Speed 300 Cycles/Min
Accuracy of Cutting ±0.15 mm
Max Die Cutting Area 381mmx320mm(LxW)
Paper Width 80mm ~330mm
Max Unwinding Dia. 700mm (≈2000meters)
Max Rewinding Dia. 700mm (≈2000meters)
Repeat Length of Die Cutting 50mm ~330mm
MOTOR Power 10kw
Overall Diameter ( L×W×H ) 29 50×1400×1700mm
Weight 3000KGS
Features
  • Unwinder web guiding
  • Semi-rotary die cutter
  • Slitter
  • Rewinder
  • Sheeter
Standard configuration

A: Unwinding
B: Web Guider
C: 120teeth/381mmmagnetic cylinder (15 inch cylinder)
D: Servo motors (Panasonic imported from Japan)
E: HMI touch screen operating system (Schneider PLC)
F: Rewinder and waste matrix mandrels

Options
No Items Description
1 Platform for digital inkjet Suction platform with blank position
2 Fully UV coating Fully rotary flexo printer without register
2.1 Register Flexo system Re-register flexo printing
2.2 UV lamp 200W/cm Supports customers' brand installation
2.3 Hot air system
3 Laminator Common Bopp laminator
3.1 Over lamination Supports cold foil system/liner rewind up
4 Hot lamination Heater for glued film
6 Slitting unit Shear slitting (3 set blades)
6.1 Razor slitter
6 Sheeting & paper collecting table Manual collection
7 Corona & dust proof
8 Cart Installs roll material
