Automatic Blister Packing Machine DPP Series
Request a Quote
The DPP automatic blister packing machine is an ideal blister packing machine for small sized pharmaceutical factories, health care product factories and food industry factories. With an imported frequency transformer, adjustable stroke, manual wheel and stainless steel structure, this automatic blister packing machine features a simply operation and a high output.
Specifications
| Model | DPP-88 | |
| Production Capacity(Cycle/min) | 20-40 | |
| Range of stroke(mm) | 20-100 | |
| Packing material | Pharmacy PVC (mm) | (0.2-0.4)×88 |
| PTP alu foil (mm) | (0.02-0.05)×88 | |
| Compressed air(pressure) | 0.6-0.8MPa | |
| Air consumption(m3/min) | ≥0.2 | |
| Power Supply | AC220V/380V 50HZ 1.8KW | |
| Overall dimension(L×W×H) | 900*460*890 | |
| Net weight (kg) | 350 | |
| Model | DPP-140 | DPP-250 | DPP-350 | |
| Production Capacity(Cycle/min) | 20-40 | 20-45 | 20-40 | |
| Range of stroke(mm) | 40-120 | 40-120 | 40-120 | |
| Packing material | Pharmacy PVC (mm) | (0.2-0.4)×140 | (0.2-0.4)×250 | (0.2-0.4)×350 |
| PTP alu foil (mm) | (0.02-0.05)×140 | (0.02-0.05)×250 | (0.02-0.05)×350 | |
| Compressed air(pressure) | 0.6-0.8MPa | 0.6-0.8MPa | 0.6-0.8MPa | |
| Air consumption(m3/min) | ≥0.2 | ≥0.3 | ≥0.4 | |
| Power Supply | AC220V/380V 50HZ | AC380V 50HZ 6.5KW | AC380V 50HZ 10KW | |
| 5KW | ||||
| Water chiller for moulds | Tap water or recycle water with 60L/h consumption | |||
| Overall dimension(L×W×H) | 3200×650×1700 | 3200×750×1700 | 3700×750×1700 | |
| Net weight (kg) | 1200 | 1700 | 2300 | |
