Automatic Capsule Filling Machine, NJP -260C Series
Request a Quote
Filled with Liquid and Oil
The automatic capsule filling machine is specially designed to produce liquid-filled hard capsules. This capsule filling equipment adopts automatic frequency control of motor speed, making the operation easy and convenient. Equipped with an innovative dosing filling system, it's ideally suitable for use in the pharmaceutical, food, health care products industry.
Specifications
| Model | NJP-260C |
| Max. capacity | 260pcs/min |
| Capsule filling type | 00#~5#capsule |
| Filling Precision | ≥99.5% |
| Noise | ≤75dBA |
| Liquid filling quantity accuracy | Liquid 300mg≤±3% |
| Compressed air (pressure) | 0.06m³/min 0.3Mpa |
| Water requirement | Tap water or recycle water |
| Vacuum | ﹣0.02~﹣0.06 Mpa |
| The amount of water | 250L/h |
| Incoming water pipe internal Dia. | 20mm |
| Drain-pipe internal Dia. | 27mm |
| Working Temperature | 21℃±3℃ |
| Working humidity | 40~55% |
| Air displacement | 300 m³/h |
| Control System | Inverter & PLC control |
| Max. capacity | 177,000pcs/h |
| Motor | 5.75KW |
| Power Supply | 380V 50Hz 3PH |
| Overall size | 1020*860*1970mm |
| Net weight | 900kg |
