Application
Geotechnical centrifuges are widely used in engineering applications, including dams, side slopes, roadbeds, tunnels, building foundations and more. They extend the application range in exploring different natural phenomenon, including earthquakes, geotechtonic and abnormal geological formation.

Parameters
Type Effective rotation radius(m)Accelerated speed(g) Effective load Model box size (m) Main technical features
TLJ-25 1.5 250 100g, 250kg, 250g, 100kg 0.59x0.4x0.4 25g.t, centrifugal test, static measurement
TLJ-60 2.7 200 100g, 600kg; 200g, 300kg 0.7x0.36x0.5 0.5x0.36x0.4 60g.t, centrifugal test,photography, camera shooting, static measurement
TLJ-60A 2.7 200 100g, 600kg; 200g, 300kg 0.7x0.6x0.4 0.6x0.5x0.35 60g.t, centrifugal test, static measurement
TLJ-100 2.7 200 100g, 200kg; 200g, 100kg 0.5x0.5x0.7 0.4x0.4x0.4 100g.t, centrifugal test, photography, camera shooting, dynamic static measurement
TLJ-150 3.5 200 100g, 1500kg 200g, 750kg 0.7x0.7x0.9 0.5x0.5x0.8 150g.t, centrifugal test, one-dimensional vibration table, manipulator for piling, pile pulling and digging, photography, camera shooting, dynamic and static measurement
TLJ-150A 3.5 150 100g, 1500kg, 10g, 1000kg 0.7x0.7x0.9 0.7x0.36x0.9 150g.t,centrifugal test, photography, camera shooting, static measurement. Vibrating tables, manipulator reservation
TLJ-200 3.7 200 200g, 1000kg Nacelle volume without anything: 1.2x0.9x1.5 200g.t, centrifugal test, photography, camera shooting, static measurement.manipulator, Vibrating tables reservation
TLJ-400 4.2 150 150g, 2700kg Nacelle volume without anything:1.5x1.2x1.5 400g.t, centrifugal test, one-dimensional vibration table, photography, camera shooting, dynamic static measurement
