Sludge Dewatering Centrifuge
Request a Quote
Application
Sludge dewatering centrifuge is a kind of sludge treatment equipment which can run continuously.
| Type | LW450x1885 | LW350x1450 |
| Inner diameter of centrifuge bowl with bigger size(mm) | 450 | 350 |
| Draw ratio | 4.2 | 4.1 |
| Differential speed(r/min) | 2~15 continuously adjustable | |
| Highest speed of centrifuge bowl(r/min) | 3200 | 3500 |
| Max separation factor | 2560 | 2382 |
| Handling capacity with suspension(m³/h) | 15~30 | 8~15 |
| Discharge capacity of solid-phase materials (with wet residue t/h) | 1.8 | 1.1 |
| Power of electric motor(kw) | 30 | 22 |
| Overall dimensions(length X width X height)(mm) | 3300x1600x960 | 2800x1500x930 |
| Moisture ratio of sludge cake | ≤75% | |
| Flocculant dosage(Kg/TDS) | 2-4 | |
| Running time | Running 24 hours continuously | |
| | ||
- Sludge dewatering centrifuge can be operated continuously and it has big processing capacity.
- This equipment adopts fully closed design and it is equipped with the residual liquid recovery unit which can avoiding secondary pollution in work site.
- The centrifuge bowl and feed tube adopt stainless steel structure.
- The inner surface of centrifuge bowl is equipped with skid resistance grooves.
- Residue discharge, feeding and helical blade adopt wear resistance castings.
- Sludge dewatering centrifuge adopts dual-motor variable frequency adjusting speed which can ensure the highest flexibility.
- The Sludge dewatering centrifuge adopts PLC control system and fieldbus technology, which can realize closed loop control of torque, differential speed, feed flow rate and flocculant dosage. Additionally, it can realize the real-time monitoring of overload, motor current, bearing temperature, vibration severity and so on.
