Application
Powder weighing bagging machine can accomplish 25-50kg quantitative packing. It can be used to do measure, filling, seal for open top bags weaved by plastic, clamping and so on.

Applicable materials
Materials in the form of powder, such as cement, dry powder mortar, calcium powder, lime powder, gypsum powder, putty powder, zeolite powder and so on.

Parameters

Item	Parameter
Power supply mode	Three-phase four-wire motor
Power voltage	220V/50HZ-60HZ
Temperature	-10℃～+45℃
Weighing accuracy	±0.1%～0.5%
Weighing range	25～50kg
Production capacity	≤10～15t/h
Packaging speed	150～300/h
Air pressure	0.4～0.8Mpa
Belt running speed	3.6～18m/min
Height of packaging bags	600～900mm

Parameter

Item	Unit	Technology parameter
Production type		LXB50-Ⅰ		LXB50-Ⅱ	LXB50-Ⅲ	LXB50-Ⅳ
Discharging mouth		1		2	3	4
Production capacity	t/h	10~15		20~30	30~45	40~60
Discharge power	Kw	4		4×2	4×3	4×4
Weighing range	㎏	20~50(can be adjusted)
Measuring accuracy	㎏	±0.3
Bag weight pass rate	≥95％
Feeding flange	㎜	280×260	620×260		1350×260	1845×260
Machine weight	㎏	500	850		1080	1360
Length ×width×height880E/880A	mm	680×1150×1330	1140×1150×1330(1780)		1760×1150×1330(1780)	2280×1150×1330(1780)

Advantages

Power weighing bagging machine consists of automatic weighing device, conveying device, sewing device and instrument control device.
The bagging machine has the advantages of proper structure, attractive appearance, stable running, saving energy, convenient operation and accurate weighing.
