200W Drive Motor, PMDC Brushless Motor TF095CH
Request a Quote
Your Motion
Application: power wheelchair
Technical Specifications
| Rated Power (W) | 200 |
| Rated Voltage(V) | 24 |
| No-load Current(A) | ≤1.7 |
| No-load Revolution (RPM) | 3450 |
| Rated Torque(N•m) | 0.74 |
| Rated Revolution (RPM) | 2600 |
| Rated Current(A) | ≤14.0 |
| Rated Efficiency (%) | ≥75 |
| Working Cycle (min.) | S2-60 |
| Insulation Class | F |
| Protection Level | IP44 |
| Gear Ratio | 17.75 |
| Length (mm) | 205 |
Note: we can customize any brushless DC drive motor according to your application requirements and working conditions.
