Basic Controls’ clamp for ultrasonic flow meters features the clamp on the installation design. As it comes into no contact with the flow media, it is fast and easy to install. The meter interior is designed as a modular structure, allowing for a high reliability and low maintenance cost. This flow meter can be used for the measurement of underground water, potable water, waste water and other liquids.

This flow meter has a small calculator and a small sensor weighing only 0.5kg, making it easy to carry.

Parameters

Flow rate range	0～±5m/s
Measuring accuracy	0.7～3.5m/s
Repeatability	0.004
Diameter range	25～600mm
Measuring medium	water
Materials	Carbon steel, stainless steel, PVC (optional)
Analog output	4～20mA
Maximum load resistance	750Ω
Power supply	24V DC, max. current≥1A
Keypad	4×4 tactile keys
Display screen	20×2 characters, LCD with backlight
Operating temperature	Installing temperature of the transmitter: -10℃～50℃
Operating temperature	Temperature of the measured medium by sensor: 2℃～95℃
Relative humidity	0～99%
Transmitter shell material	PC/ABS plastics
Protection grade	IP65
Sensor protection grade	IP68
Standard cable length	9m
Transmitter weight	0.7kg
Sensor weight	0.5kg
