NEW DODO-300 Automatic Canbody Welder
Request a Quote
The automatic canbody welder is designed for rounding and welding processes for the production of high quality three-piece metal can bodies. The production output of this welder is up to 300 cans/min.
Features
- The automatic canbody welder is equipped with a simple to use interface, PLC system, and servo system.
- Its static variable frequency power source provides stability and energy savings.
- A special rounding device can process various types of tinplate for different can bodies.
- The copper wire profiling roller and Z-rail are made of wear-resistant ceramics.
- Automatic scoring unit, remote control system and weld seam detection system are all optional.
Technical Specifications
| Welding speed | 40m/min（max） |
| Production output | 300cans/min（Max） |
| Can inner diameter range | Φ52～Φ99mm |
| Height range | 60～180mm |
| Welding points distance | 0.5～0.9mm |
| Overlap width | 0.25～0.4mm |
| Sheet thickness | 0.14～0.30mm |
| Temper | T2.5～DR8 |
| Wire diameter | Φ1.24～1.38mm |
| Electrical mains | Three phase Voltage: 380V |
| Welding frequency | 180-400Hz |
| Cooling water | >0.4MPa, 12-18℃, 40L/min |
| Air pressure and consumption | >600L/min, >0.6MPa |
