SAM 836 Wheel Loader
Request a Quote
This product has been discontinued and removed from our shelves.
Features
- The cab of SAM 836 wheel loader has the big inner space, full field of view, comfortable suspension seat, and user friendly console.
- The advanced, reliable engine is powerful in performance and features low fuel consumption and emission.
- High strength reserve gear box and driving axle show reliable mechanical properties.
- The high quality hydraulic pipeline purchased from famous suppliers has the well-designed layout.
- The sturdy, durable hatchback metal engine hood makes the easy maintenance of engine.
- Due to optimized, computer-designed operating devices, the wheel loader offers the high unloading height, light and nimble operation, stable and reliable action.
Technical Parameters
| Performance | Rated load | 3000kg | Engine | Model | WP6G125E22 |
| Overall weight | 9600kg | Type | Inline water cooling four stroke | ||
| Bucket capacity | 1.7-2.5m3 | ||||
| Maximum tractive force | 97KN | NO. of cylinder-bore×stroke | 6-108×125mm | ||
| Maximum breakout force | 127KN | Rated power | 92kw | ||
| Maximum grade ability | 30° | Maximum torque | 500N.m | ||
| Maximum dump height | 3100mm | Hydraulic system | Minimum fuel consume ratio | ≤210Kw.h | |
| Maximum dump reach | 1006mm | ||||
| Overall Dimension (L*W*H) | 689×243×3070mm (L*W*H) | System working pressure | 16.5MPa | ||
| Minimum turning radius | 5097mm | Boom lifting time | 4.83s | ||
| Transmission | Torque converter | YJ315-X | Total time | 9.15s±0.5s | |
| Gearbox mode | Power shift normally engaged straight gear | Fuel tank capacity | 156L | ||
| Gears | 4forward3reverse | Function of leveling automatically | Yes | ||
| Maximum speed | 40km/ h | ||||
| Drive axles | Main reducingSpiral | Bevel gear grade 1 reduction | Brake system | Service brake | Air over hydraulic disc brake on 4 wheels |
| Decelerating mode | Planetary reduction grade 1 | Parking brake | Manual disk brake | ||
| Wheel base(mm) | 2660mm | Tyre | Type specification | 17.5-25 | |
| Wheel tread | 1800mm | Front tyre pressure | 0.4MPa | ||
| Minimum ground clearance | 400mm | Rear tyre pressure | 0.35MPa |
