400W Reduction Hub Motor, PMDC Brushless Motor GF068ALH
Request a Quote
Your Motion
Application: electric material handling equipment
Technical Specifications
| Rated Power (W) | 400 |
| Rated Voltage(V) | 24 |
| No-load Current(A) | ≤4.5 |
| No-load Revolution (RPM) | 5000±8% |
| Rated Torque (N•m) | 0.88 |
| Rated Revolution (RPM) | 4350±8% |
| Rated Current(A) | ≤22.2 |
| Working Cycle (min.) | S2-30 |
| Insulation Class | F |
| Protection Level | IP33 |
| Gear Ratio | 19:1 |
| Length (L/mm) | 152 |
Note: customized brushless DC hub motor is available according to your application requirements and working conditions.
