Hydrostatic press is a machine utilizing liquid as the actuating medium to transfer energy and to realize a specific process. Apart from plate forging, hydraulic press is also used for straightening, mounting, briquetting, plate pressing, plate bending, and plate straightening, etc. Chaoli hydrostatic presses are classified into water press and oil press: machines utilizing water fluid as the actuating medium are called water presses and machines adopting oil to be the actuating medium are oil presses. The type of hydrostatic press is commonly indicated by nominal working force (kN) or nominal tonnage (T). Water press is generally used for plate forging due to its large tonnage.

The structure of the hydraulic press shall be more compact with less rolls, bigger roll diameter and larger power (width unchanged) for processing thicker sheet, vise versa. Carrier rolls (pulleys) are arranged outside of the upper and lower working rolls to form a roller group structure. This 4-column hydraulic press is generally consisted of a driving part, a motor and an electric control unit.

Technical parameters of the hydraulic press

400kN Hydraulic Press

Model		YJZ32-40
Nominal pressure (kN)		400
Ejector force (kN)		12
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		400
Max stroke of the ejection piston (mm)		150
Opening height (mm)		600
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	10
	returning (mm/s)	52
Effective dimension of the working table	length (mm)	500
	width (mm)	460
Overall dimensions of the machine	length (mm)	1800
	width (mm)	1200
	height (mm)	2600
Motor power (kw)		4

630kN Hydraulic Press

Model		YJZ32-63
Nominal pressure (kN)		630
Ejector force (kN)		190
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		500
Max stroke of the ejection piston (mm)		160
Opening height (mm)		700
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	25
	returning (mm/s)	80
Effective dimension of the working table	length (mm)	560
	width (mm)	500
Overall dimensions of the machine	length (mm)	2400
	width (mm)	1400
	height (mm)	3100
Motor power (kw)		7.5

1000kN Hydraulic Press

Model		YJZ32-100	YJZ32-100E
Nominal pressure (kN)		1000	1000
Ejector force (kN)		190	400
Max hydraulic pressure (MPa)		25	25
Max sliding stroke (mm)		600	600
Max stroke of the ejection piston (mm)		200	200
Opening height (mm)		900	900
Sliding speed of the slider	moving downward with no load (mm/s)	100	120
	working (mm/s)	10	16
	returning (mm/s)	50	80
Effective dimension of the working table	length (mm)	720	750
Effective dimension of the working table	width (mm)	580	640
Overall dimensions of the machine	length (mm)	2500	2700
	width (mm)	1500	1700
	height (mm)	3150	3400
Motor power (kw)		7.5	11

1600kN Hydraulic Press

Model		YJZ32-160C
Nominal pressure (kN)		1600
Ejector force (kN)		400
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		700
Max stroke of the ejection piston (mm)		250
Opening height (mm)		1000
Sliding speed of the slider	moving downward with no load (mm/s)	120
	working (mm/s)	10
	returning (mm/s)	50
Effective dimension of the working table	length (mm)	1000
	width (mm)	800
Overall dimensions of the machine	length (mm)	2700
	width (mm)	1700
	height (mm)	3400
Motor power (kw)		11

2000kN Hydraulic Press

Model		YJZ32-200A
Nominal pressure (kN)		2000
Ejector force (kN)		4000
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		700
Max stroke of the ejection piston (mm)		250
Opening height (mm)		1100
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	12
	returning (mm/s)	80
Effective dimension of the working table	length (mm)	1000
	width (mm)	900
Overall dimensions of the machine	length (mm)	2825
	width (mm)	1500
	height (mm)	3725
Motor power (kw)		15

3150kN Hydraulic Press

Model		YJZ32-315A
Nominal pressure (kN)		3150
Ejector force (kN)		630
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		800
Max stroke of the ejection piston (mm)		300
Opening height (mm)		1200
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	12
	returning (mm/s)	60
Effective dimension of the working table	length (mm)	1250
	width (mm)	1200
Overall dimensions of the machine	length (mm)	3235
	width (mm)	1500
	height (mm)	4295
Motor power (kw)		18.5

4000kN Hydraulic Press

Model		YJZ32-400
Nominal pressure (kN)		4000
Ejector force (kN)		630
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		800
Max stroke of the ejection piston (mm)		300
Opening height (mm)		1300
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	12
	returning (mm/s)	45
Effective dimension of the working table	length (mm)	1250
	width (mm)	1200
Overall dimensions of the machine	length (mm)	3235
	width (mm)	1500
	height (mm)	4500
Motor power (kw)		22

5000kN Hydraulic Press

Model		YJZ32-500B	YJZ32-500C
Nominal pressure (kN)		5000	5000
Ejector force (kN)		1000	1000
Max hydraulic pressure (MPa)		25	25
Max sliding stroke (mm)		900	900
Max stroke of the ejection piston (mm)		350	350
Opening height (mm)		1500	1500
Sliding speed of the slider	moving downward with no load (mm/s)	100	100
	working (mm/s)	12	12
	returning (mm/s)	80	80
Effective dimension of the working table	length (mm)	1400	2200
Effective dimension of the working table	width (mm)	1400	1400
Overall dimensions of the machine	length (mm)	4060	6500
	width (mm)	1800	1800
	height (mm)	4995	4740
Motor power (kw)		37	37

6300kN Hydraulic Press

Model		YJZ32-630
Nominal pressure (kN)		6300
Ejector force (kN)		1000
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		900
Max stroke of the ejection piston (mm)		350
Opening height (mm)		1500
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	12
	returning (mm/s)	50
Effective dimension of the working table	length (mm)	1500
	width (mm)	1500
Overall dimensions of the machine	length (mm)	4200
	width (mm)	2000
	height (mm)	5600
Motor power (kw)		45

8000kN Hydraulic Press

Model		YJZ32-800
Nominal pressure (kN)		8000
Ejector force (kN)		1600
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		900
Max stroke of the ejection piston (mm)		450
Opening height (mm)		1600
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	8
	returning (mm/s)	50
Effective dimension of the working table	length (mm)	1800
	width (mm)	1600
Dimension of the machine	length (mm)	4800
	width (mm)	4000
	height (mm)	6000
Motor power (kw)		45

10000kN Hydraulic Press

Model		YJZ32-1000
Nominal pressure (kN)		10000
Ejector force (kN)		1600
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		900
Max stroke of the ejection piston (mm)		450
Opening height (mm)		1600
Sliding speed of the slider	moving downward with no load (mm/s)	80
	working (mm/s)	10
	returning (mm/s)	50
Effective dimension of the working table	length (mm)	2000
	width (mm)	1800
Dimension of the machine	length (mm)	5200
	width (mm)	4300
	height (mm)	6450
Motor power (kw)		60

12500kN Hydraulic Press

Model		YJZ32-1250
Nominal pressure (kN)		12500
Ejector force (kN)		2000
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		900
Max stroke of the ejection piston (mm)		450
Opening height (mm)		1600
Sliding speed of the slider	moving downward with no load (mm/s)	80
	working (mm/s)	8
	returning (mm/s)	50
Effective dimension of the working table	length (mm)	2000
	width (mm)	1800
Dimension of the machine	length (mm)	5200
	width (mm)	4300
	height (mm)	6450
Motor power (kw)		60

16000kN Hydraulic Press

Model		YJZ32-1600
Nominal pressure (kN)		16000
Ejector force (kN)		2000
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		1000
Max stroke of the ejection piston (mm)		300
Opening height (mm)		1800
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	10
	returning (mm/s)	80
Effective dimension of the working table	length (mm)	2400
	width (mm)	2000
Dimension of the machine	length (mm)	6500
	width (mm)	4500
	height (mm)	6500
Motor power (kw)		≈120

20000kN Hydraulic Press

Model		YJZ32-2000
Nominal pressure (kN)		20000
Ejector force (kN)		2000
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		1200
Max stroke of the ejection piston (mm)		300
Opening height (mm)		2000
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	10
	returning (mm/s)	70
Effective dimension of the working table	length (mm)	2500
	width (mm)	2000
Dimension of the machine	length (mm)	6500
	width (mm)	4500
	height (mm)	6800
Motor power (kw)		≈145

25000kN Hydraulic Press

Model		YJZ32-2500
Nominal pressure (kN)		25000
Ejector force (kN)		2500
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		900
Max stroke of the ejection piston (mm)		450
Opening height (mm)		1800
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	10
	returning (mm/s)	60
Effective dimension of the working table	length (mm)	2500
	width (mm)	2380
Dimension of the machine	length (mm)	6600
	width (mm)	4500
	height (mm)	8450
Motor power (kw)		≈145

30000kN Hydraulic Press

Model		YJZ32-3000
Nominal pressure (kN)		30000
Ejector force (kN)		2500
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		1200
Max stroke of the ejection piston (mm)		450
Opening height (mm)		1800
Sliding speed of the slider	moving downward with no load (mm/s)	120
	working (mm/s)	10
	returning (mm/s)	80
Effective dimension of the working table	length (mm)	4000
	width (mm)	2500
Dimension of the machine	length (mm)	9000
	width (mm)	4600
	height (mm)	10000
Motor power (kw)		≈180

35000kN Hydraulic Press

Model		YJZ32-3500
Nominal pressure (kN)		35000
Ejector force (kN)		3150
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		1200
Max stroke of the ejection piston (mm)		450
Opening height (mm)		2500
Sliding speed of the slider	moving downward with no load (mm/s)	120
	working (mm/s)	10
	returning (mm/s)	100
Effective dimension of the working table	length (mm)	4000
	width (mm)	1500
Dimension of the machine	length (mm)	8000
	width (mm)	2500
	height (mm)	11000
Motor power (kw)		≈250

40000kN Hydraulic Press

Model		YJZ32-4000
Nominal pressure (kN)		40000
Ejector force (kN)		4000
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		900
Max stroke of the ejection piston (mm)		360
Opening height (mm)		1500
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	8
	returning (mm/s)	60
Effective dimension of the working table	length (mm)	5000
	width (mm)	1600
Dimension of the machine	length (mm)	12100
	width (mm)	3700
	height (mm)	7650
Motor power (kw)		≈350

50000kN Hydraulic Press

Model		YJZ32-5000
Nominal pressure (kN)		50000
Ejector force (kN)		8000
Max hydraulic pressure (MPa)		25
Max sliding stroke (mm)		900
Max stroke of the ejection piston (mm)		350
Opening height (mm)		1500
Sliding speed of the slider	moving downward with no load (mm/s)	100
	working (mm/s)	8
	returning (mm/s)	80
Effective dimension of the working table	length (mm)	5000
	width (mm)	1600
Dimension of the machine	length (mm)	12100
	width (mm)	3700
	height (mm)	7850
Motor power (kw)		≈450
