Aluminum Lid Die Punching Machine, CLB Series
Request a Quote
CLB series fully automatic die punching machine is primarily designed for efficient punching of aluminum foil and paper rolls with thickness of 60-120gsm. It is suitable for manufacturing ice cream cone sleeves, ice cream cup lids, instant noodle lids, paper cup foil lids, and various types of food packaging wraps. Automatic waste rewinder is available.
Technical Specifications
| Model | CLB500 | CLB700 |
| Max. paper width | 490mm | 690 |
| Max. punching area | 460×300mm | 660×300mm |
| Cutting precision | ±0.20mm | |
| Paper weight | Paper Gsm : 60-120g/m2, Thickness: ≥0.06mm (aluminum foil, laminated paper, plain aluminum) | |
| Machine speed | 100-200times/min | |
| Air pressure | 0.6Mpa | |
| Air consumption | 0.25m³/min | |
| Weight | 4T | 5T |
| Max. web roll diameter | 800mm | |
| Total power | 10kW | |
