Seam Welder
Request a Quote
1. AC Seam Welding
| Specification / Model | FN-200 H | FN-200 Z |
| Power | 200 KVA | 200KVA |
| Capacity | 10 kN | 10 kN |
| Vertical Stroke | 100 mm | 100 mm |
| Throat Depth | 800 mm | 800 mm |
| Electrode Diameter | 300 mm | 300 mm |
| Welding Speed Max | 2000 mm/min | 2000 mm/min |
2. DC Seam Welding
| Specification / Model | FZ-200 | FZ-3X160 Z |
| Power | 200 KVA | 3X160 KVA |
| Capacity | 10 kN | 15 kN |
| Vertical Stroke | 100 mm | 120 mm |
| Throat Depth Max. | 800 mm | 1000 mm |
| Electrode Diameter | 300 mm | 300 mm |
| Welding Speed Max | 2000 mm/min | 2000 mm/min |
