Bullet Feet
These bullet feet are compact and extremely durable. They are designed with square or round tubing with various diameters. They are widely applied for light-duty commercial kitchen equipment such as counters, racks, and vertical wash basins.
The hex steel foot makes it easy to adjust. The flanged foot offers additional stability. According to your kitchen equipment and areas of use, we can work with you to find the most ideal bullet feet for your kitchen equipment.
Bullet feet are commonly made of plastic, stainless steel or zinc alloy. The load-bearing capacity ranges from 100kgs to 800kgs. The adjustment range is 1 inch.
Square tubing diameters: 25x25/30x30x32/32x38x38x40x40/50.8x50.8mm
Round tubing diameters: φ25mm, φ30mm, φ38mm, φ41mm, φ50.8mm, φ63mm
- Model: DG1016-Y25-1
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
25mm round tubing -
- Model: DG1016-Y25-2
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
25mm round tubing
-
- Model: DG1111-Y30
Material: Stainless steel clad plastic
Loading capacity: 100kgs
Tubing diameter:
30mm round tubing
-
- Model: DG1011-Y30
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
30mm round tubing
-
- Model: D2111-Y38
Material: Zinc alloy
Loading capacity: 600kgs
Tubing diameter:
38mm round tubing
-
- Model: DG5115-Y38
Material: Steel
Loading capacity: 300kgs
Tubing diameter:
38mm round tubing
-
- Model: D1116-Y38
Material: Stainless steel clad plastic
Loading capacity: 80kgs
Tubing diameter:
38mm round tubing
-
- Model: D1111-Y38
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
38mm round tubing
-
- Model: D1011-Y38
Material: Nylon
Loading capacity: 100kgs
Tubing diameter:
38mm round tubing
-
- Model: DG1111-Y38
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
38mm round tubing
-
- Model: DG1117-Y38
Material: Stainless steel clad nylon
Loading capacity: 100kgs
Tubing diameter:
38mm round tubing
-
- Model: DG1011-Y38
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
38mm round tubing
-
- Model: D1116-Y41
Material: Plastic
Loading capacity: 100kgs
Tubing diameter:
41mm round tubing
-
- Model: D1111-Y41
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
41mm round tubing
-
- Model: D1016-Y41
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
41mm round tubing
-
- Model: D2111-Y41
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
41mm round tubing
-
- Model: DL2111-Y41
Material: Steel
Loading capacity: 300kgs
Tubing diameter:
41mm round tubing
-
- Model: D1011-Y51
Material: Nylon
Loading capacity: 150kgs
Tubing diameter:
51mm round tubing
-
- Model: D1011-Y51L
Material: Nylon
Loading capacity: 150kgs
Tubing diameter:
51mm round tubing
-
- Model: DG1011-Y51
Material: Plastic
Loading capacity: 100kgs
Tubing diameter:
51mm round tubing
- Model: DG1111-Y51
Material: Stainless steel clad plastic
Loading capacity: 150kgs
Tubing diameter:
51mm round tubing - Model: DG5115-Y51
Material: Steel
Loading capacity: 300kgs
Tubing diameter:
51mm round tubing - Model: D2111-Y51
Material: Zinc alloy
Loading capacity: 1000kgs
Tubing diameter:
51mm round tubing - Model: D5114-Y51
Material: Steel
Loading capacity: 300kgs
Tubing diameter:
51mm round tubing - Model: D5114-Y63
Material: Steel
Loading capacity: 500kgs
Tubing diameter:
51mm round tubing - Model: D2013-F25
Material: Zinc alloy
Loading capacity: 500kgs
Tubing diameter:
25mm square tubing - Model: D1011-F25
Material: Nylon
Loading capacity: 80kgs
Tubing diameter:
25mm square tubing - Model: DG2012-F30
Material: Zinc alloy
Loading capacity: 500kgs
Tubing diameter:
30mm square tubing - Model: F3011-F30 Material:
Loading capacity:
Tubing diameter:
- Model: DG1111-F30
Material: Stainless steel clad plastic
Loading capacity: 100kgs
Tubing diameter:
30mm square tubing - Model: DG1011-F30
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
30mm square tubing - Model: D2013-F32
Material: Zinc alloy
Loading capacity: 300kgs
Tubing diameter:
32mm square tubing - Model: F2023-F32
Material: Zinc alloy
Loading capacity: 500kgs
Tubing diameter:
32mm square tubing - Model: F2022-F32
Material: Zinc alloy
Loading capacity: 500kgs
Tubing diameter:
32mm square tubing - Model: D1011-F32
Material: Nylon
Loading capacity: 100kgs
Tubing diameter:
32mm square tubing - Model: D2212-F38
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
38mm square tubing - Model: F2112-F38
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
38mm square tubing - Model: DG4213-F38
Material: Steel
Loading capacity: 300kgs
Tubing diameter:
38mm square tubing - Model: DG1117-F38
Material: Stainless steel clad nylon
Loading capacity: 100kgs
Tubing diameter:
38mm square tubing - Model: DG1111-F38
Material: Plastic
Loading capacity: 100kgs
Tubing diameter:
38mm square tubing - Model: DG1011-F38
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
38mm square tubing - Model: D1011-F38
Material: Nylon
Loading capacity: 100kgs
Tubing diameter:
38mm square tubing - Model: DL2212-F38
Material: Stainless steel
Loading capacity: 300kgs
Tubing diameter:
38mm square tubing - Model: D2212-F40
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
40mm square tubing - Model: D2112-F40
Material: Stainless steel clad plastic
Loading capacity: 800kgs
Tubing diameter:
40mm square tubing - Model: D1211-F40
Material: Plastic
Loading capacity: 100kgs
Tubing diameter:
40mm square tubing - Model: DG1211-F40
Material: Plastic
Loading capacity: 100kgs
Tubing diameter:
40mm square tubing - Model: D2111-F51
Material: Zinc alloy
Loading capacity: 1000kgs
Tubing diameter:
51mm square tubing - Model: DG4213-F51
Material: Steel
Loading capacity: 300kgs
Tubing diameter:
51mm square tubing - Model: DG1011-F51
Material: Plastic
Loading capacity: 80kgs
Tubing diameter:
51mm square tubing - Model: F2121-Y38(50)
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
38mm round tubing - Model: F2111-Y38(89)
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
38mm round tubing - Model: F2121-Y41(89)
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
41mm round tubing - Model: F2111-Y41(L)
Material: Stainless steel
Loading capacity: 300kgs
Tubing diameter:
41mm round tubing - Model: F2222-F38(50)
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
40mm square tubing - Model: F2212-F38(89)
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
38mm round tubing - Model: F2222-F40(50)
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
40mm square tubing - Model: F2222-F40(89)
Material: Zinc alloy
Loading capacity: 800kgs
Tubing diameter:
40mm square tubing - Model: F2121-F51(89)
Material: Zinc alloy
Loading capacity: 1000kgs
Tubing diameter:
51mm square tubing
