Main Advantages
  • The varnishing die cutter is cost-efficient, which is used for high quality converting and finishing.
  • The die cutting machine is designed with winding, semi or full flexo printing, semi- or full rotary die cutting, super varnishing, and can be optionally configured with cold foiling, IML system, slitting, sheeting, laminating, etc.
  • Fully servo driven operation provides high productivity.
Technical Parameters
Max Web Width 330mm
Max Die-cutting Speed (full-rotary) 110m/mim
Max Die-cutting Speed (semi-rotary) 60m/min
Max Flexo Printing Speed (full-rotary) 90m/min
Max Flexo Printing Speed (semi-rotary) 60m/min
Registration Accuracy ±0.15mm
Standard Magnetic Die-cutting Cylinder 152T
Optional Magnetic Die-cutting Cylinder 60T~204T
Max Unwinder dia. 700mm
Max Rewinder dia. 700mm
Min Slitting width 16mm
Adhesive Die-cutting Accuracy ±0.15mm
Accuracy of IML Cutting ±0.25mm
Total Motor Power 19kW~21kW
Registration Mark Sensor
Dimension 3650×1260×2025 mm
Weight 3600KGS
  • Unwinder & Web Guiding
    1.Unwinder with closed-loop tension control.
    2.Electronic web guide with ultrasonic edge guide sensor.
    3.76 mm air expanding mandrel.
    4.Optional roll diameter: 700 mm–1000 mm
  • Flexo Printing Unit
    1.Independent, servo-driven semi-or full rotary printing unit with auto pre-positioning and registration.
    2.Optional reverse side printing.
    3.Printing repeat lengths of 50 mm-457 mm.
  • Semi- or Full Rotary Die Cutting
    1.Independent and servo-driven.
    2.Repeat lengths from 50 mm-330 mm for semi-rotary, and 190.5 mm-476.25 mm for full rotary.
    3.Magnetic or solid/engraved cylinders.
  • Cold Foil & Super Varnish
    1.Cold-foil and super varnish with two pneumatic shafts and unwind/rewind.
  • Slitting Options
    1.Add shear slitting knives.
    2.Increase productivity with automatic shear slitting to control the knives from the user-interface.
    3.Optional razor blades.
  • IML System
    1.IML die-cutting system designed for easy installation and removal.
    2.Static eliminator in label output collection table works with counter and stepless speed regulation.
  • Rewinding Options
    1.Standard single rewind.
    2.Upgrade to dual rewind, or a productive Turret rewinder with buffer and automatic cutting of the web for optimal productivity.
