Stone VSI Crusher Plant
Request a Quote
- Featuring a high-performance vertical shaft impact (VSI) crusher with optional dual-chamber or four-chamber rotors. This configuration makes it suitable for a variety of mineral crushing and shaping tasks.
- The equipment is configured with a dual-deck return screening system, where substandard aggregates are automatically returned to the crushing chamber for re-crushing, improving the shape of the finished product and increasing the sand production rate.
- The smart PLC control system enables remote monitoring and 100-meter remote wireless control operation.
- The equipment is fully pre-commissioned before shipment, allowing for quick operation once transported to the site.
- The hydraulic track drive allows for quick relocation and operation on-site.
Applicable Materials
- Metal Ores
- Non-Metal Ores
Specifications
| Model | ||||
| Feeder | Loading height (mm) | 2400 | 2500 | 2600 |
| Size (length×belt width) | 6m×B650mm | 6m×B1000mm | 6m×B1000mm | |
| Output belt conveyor | Discharge height(mm) | 3150 | 3150 | 3150 |
| Size (length×belt width) | 6m×B650mm | 7.5m×B1000mm | 7.5m×B1000mm | |
| Return screen | Screen decks | 2 | 2 | 2 |
| Model | 3YKJ1232 | 3YKJ1550 | 3YKJ1550 | |
| Transfer belt conveyor | Capacity (t/h) | 150 | 200 | 250 |
| Size (length×belt width) | 3.5m×B500mm | 3.5m×B500mm | 3.5m×B500mm | |
| Return belt conveyor | Size (length×belt width) | 10m×B500mm | 11m×B500mm | 11m×B500mm |
| Main belt conveyor | Size (length×belt width) | 8.5m×B650mm | 10m×B1000mm | 11.5m×B1000mm |
| Overall stone crusher plant | Crushing capacity (t/h) | 50-80 | 100-120 | 120-150 |
| Total power (kW) | 356 | 441 | 537 | |
