Flexo Printing Machine, ZBS-320 (1-6 Colors)
Request a Quote
- Printing speed 50m/min
- Printing color 1-6 colors
- Max. width of paper 320mm
- Max .printing width 310mm
Features
- The ceramic anilox roll is mounted in this ZBS-320 flexo printing machine for ink transferring.
- This machine is also designed with unwinding and rewinding devices controlled by magnetic powder brakes and clutches, and the Mitsubishi auto tension controller.
- Its printing unit is mounted with hot air dryer and printing plate that can be adjusted within 360°.
- With one die-cutting station, this flexo printing machine can accomplish the material feeding, printing, vanishing, drying, laminating, die cutting and rewinding at one stroke.
- It uses the ink rollers that can be automatically separated from the printing roller and keep rotating at low speed to prevent the ink from drying.
- Due to the main motor with imported continuously variable frequency speed governor, this flexo printing machine keeps stable performance effectively. Moreover, it is suitable for printing trade invoice, top grade adhesive label and other products.
Technical Specifications
| Model | ZBS-320B | ZBS-320 | ZBS-320 | ZBS-320 | ZBS-320 | ZBS-320 |
| Printing speed | 50m/min. | 50m/min. | 50m/min. | 50m/min | 50m/min. | 50m/min. |
| Printing color | 1 color | 2 colors | 3 colors | 4 colors | 5 colors | 6 colors |
| Max. width of paper | 320mm | 320mm | 320mm | 320mm | 320mm | 320mm |
| Max .printing width | 310mm | 310mm | 310mm | 310mm | 310mm | 310mm |
| Max. unwinding/rewinding diameter | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm |
| Printing length | 175-355mm | 175-355mm | 175-355mm | 175-355mm | 175-355mm | 175-355mm |
| Thickness of flexo plate | 1.7mm or 1.14mm | 1.7mm or 1.14mm | 1.7mm or 1.14mm | 1.7mm or 1.14mm | 1.7mm or 1.14mm | 1.7mm or 1.14mm |
| Precision of chromatography | ±0.1mm | ±0.1mm | ±0.1mm | ±0.1mm | ±0.1mm | ±0.1mm |
| Dimensions | 2m×1.2m×2m | 2.1m×1.2m×2.1m | 2.1m×1.2m×2.1m | 2.1m×1.2m×2.3m | 2.1m×1.2m×2.6m | 2.1m×1.2m×3.1m |
| Machine weight | About 1250kg | About 1750kg | About 1850kg | About 2000kg | About 2200kg | About 2400kg |
Shipping Information
| Packing | Export standard wooden case |
| Model No. | ZBS-320 |
| Standard | 1-6 colors |
| Productivity | 15sets per month |
| Unit Price/Payment | USD16000-USD65000 |
| H.S. Code | 84431600 |
| Trademark | WEIGANG |
| Origin | China |
| Min. Order | 1 set |
| Transportation | Land, sea, air |
Options
- Web guiding system
- UV dryer
- Separate unwinder shelf (diameter up to 900mm)
- Corona treater
- Cold stamping unit
- Video inspecting system
