Automatic Bottling Line
This automatic bottling line integrates filling, capping, and labeling into a single system, enabling continuous automated production through the interconnection of multiple machines. The production line offers strong compatibility and can be adapted to a wide range of products by changing the filling method, from low-viscosity liquids to high-viscosity sauces as well as materials containing particles. It supports multiple packaging formats, including plastic bottles, glass bottles, and barrels. Customers can flexibly configure production solutions with different operating speeds according to their budget and production capacity requirements.
| Product | Automatic Bottling Machine |
| Applicable materials | Water, juice, laundry liquid, detergent, oil, sauce, ketchup, jam, peanut butter, protein powder, nuts, freeze-dried fruit, pet food |
| Filling methods | Piston filling, rotor pump filling, screw filling, electronic weighing filling |
| Packing speed | 20–50 bottles/min |
| Filling volume | 20-5000ml |
| Filling accuracy | ±1% |
| Control system | Siemens PLC |
| No. of filling heads | 2-10 heads |
| Machine material | SUS 304 |
| Working air pressure | 0.8 MPa |
| Workflow | Bottle unscrambling → filling → cap feeding & capping → labeling → bottle arranging |
Is the machine capable of accommodating multiple pouch styles, including stand-up, zipper, and spout pouches, within a single packaging system?
Yes, we use a customized bag-loading system designed to handle different pouch types. The machine can be equipped with optional features such as bottom opening for stand-up pouches and zipper opening mechanisms for zipper bags, allowing a single machine to pack multiple pouch formats efficiently.
Can the machine be compatible with different types of materials, such as packaging both powders and granules on the same machine?
Yes, one machine can use different filling systems, such as a combination weigher for granules and an auger filler for powders.
Can one machine handle different types of bag materials?
By adjusting parameters such as sealing temperature, sealing time, and cylinder pressure, the machine can be adapted to work with different bag materials.
What is the weight accuracy of the packaging process?
The machine maintains a weight accuracy of approximately ±1%. Actual performance may vary with material characteristics such as particle size, viscosity, and adhesion. For higher precision, an optional post-packaging checkweigher system can be integrated.
How convenient is it to switch between different bag sizes, and what operations are needed for adjustment?
Yes, it’s very convenient. The main adjustments include bag loading width, bag clamping width, and the bottom opening position (for stand-up pouches).
How do I adjust the packaging equipment to accommodate different bag sizes?
- Bag Magazine Width: Adjusted via the spiral mechanism.
- Bag Clamp Distance: Set through the touch screen interface on the WHR series fully automatic rotary premade pouch filling and sealing machine.
Does the packaging equipment have multi-functional configurations?
Yes, customized solutions are available based on different materials and pouch types. Several optional features are available:
- For granule materials, choose the bag bottom vibration feature.
- For powder materials, use the bag opening dust removal function.
- For liquid materials, select the rotary air blow function to clean the bag opening.
- For spout pouches, use the specific loading method for spout bags.
- For zipper bags, enable the zipper bag opening function.
What types of products can the WHR Series Fully Automatic Rotary Premade Pouch Filling and Sealing Machine package?
The WHR series fully automatic rotary premade pouch filling and sealing machine is suitable for packaging a variety of products, including:
- Liquids: Beverages, juices, detergents, and more.
- Powders: Laundry powder, milk powder, flour, and other dry goods.
- Granules: Coffee beans, snacks, nuts, and more.
- It can handle multiple types of premade pouches, including flat, spout, zipper, stand-up, and more.
