YGT-LS331D Double Head With Double Platform Screw Driving Machine
Request a Quote
The GT-LS331D double head with double platform screw driving machine is suitable for handling products smaller than 300*300mm. Simultaneous work of the double head leads to a double production efficiency, which makes the screw driving robot a perfect choice for household appliances, electric consumer goods and photoelectric products.
Advantages
- Double Y axis double work platform with double head achieves higher screw locking efficiency.
- Two types of screw feeding systems: air output or air input type.
- Precision motor control delivers higher precision and stability.
- 5-inch true color teaching pendant is easy to learn and operate.
Parameters
Model No. | GT-LS331D | ||||
Outer dimensions | L800*W600*H740mm | ||||
Movement range | X1/X2 axis | 300mm | |||
Y1/Y2 axis | 300mm | ||||
Z1/Z2 axis | 100mm | ||||
Work platform | Double platform | ||||
Speed range | 0.1~800mm/sec | ||||
Position precision | ±0.02mm | ||||
Repetition precision | ±0.02mm | ||||
Work load | 8kg | ||||
Drive method | manual + automatic | ||||
Speed control | Automatic speed decrease and increase | ||||
undefinedEfficiency of locking screws | 0.7-1.5S/PCS | ||||
Electric screwdriver | Upon request | ||||
Screw feeding | air input/air output (optional) | ||||
Screw feeding speed | 60 screws/min | ||||
Compatible screw diameter | M0.8-M5 | ||||
Compatible screw types | Round head/ flat head/ counter sunk | ||||
Compatible screw length | 5-16mm | ||||
Compatible torque | 0.1~30kgf.cm | ||||
Program storage capacity | Unlimited | ||||
Communication port | USB | ||||
Operating temp. | 0℃~40℃ | ||||
Operating humidity | 20~90% | ||||
Air supply | 0.4~0.6Mpa | ||||
Power supply | 220V.50HZ | ||||
Weight | 30kg | 40kg | 45kg | 50kg | |
Automatic detections | Screw slippage detection | Yes | |||
undefinedScrew missing detection | Yes | ||||
Screw height detection | Yes |
