Automatic shrink sleeve label applicator for speeds up to 600BPM

DSVC-EB II is a high-speed double-head shrink sleeve labeling machine from us. When both heads are in operation simultaneously, it can achieve a maximum production speed of 600 BPM with a label length of 180mm. Widely used in the packaging industry for beverages, dairy products, and more, this automatic shrink sleeve label applicator offers various packaging options such as bottle neck, full body, and partial body labeling. The shrink sleeve labeling machine can also use thin shrink labels, significantly reducing shrink film costs, and has the ability to store labeling recipes, eliminating the need for parameter resets, thus greatly improving efficiency.

Specifications
  • Maximum Speed: 600 BPM
  • Bottle Outer Diameter: Ø25mm~Ø125mm (based on customer-provided bottle specifications)
  • Film Material: PVC/PET/OPS
  • Film Thickness: PVC: 0.035mm~0.08mm, PET: 0.04mm~0.06mm, OPS: 0.04mm~0.06mm
  • Machine Dimensions (L×W×H): 2214mm×1550mm×2752mm (our company reserves the right to modify the machine's dimensions for equipment optimization)
  • Voltage: 3-phase; 220V, 380V, 415V, 440V (according to customer requirements)
Features
  • Can be fully integrated with production and packaging lines. Equipped with protective covers and a color HMI (Human Machine Interface), allowing you to easily configure all parameters and efficiently control the production line.
  • Unique knife plate design eliminates the need for knife plate changes within the specified range; if replacement is necessary, it can be done in minutes.
  • Forced insertion design helps save production costs.
  • The thoughtful design allows for easy adjustment of the entire machine's transmission mechanism when producing labels of different sizes.
  • Can adapt to paper core with inner diameters ranging from 5" to 10", with flexible adjustments.
  • PLC transmission ensures labeling accuracy and speed.
Innovative Design
  • No need to adjust the bottle photocell sensor, allowing for flexible changes in labeling speed.
  • Can use thin shrink labels, significantly reducing shrink film costs.
  • Able to save up to ten recipes, eliminating the need to reset parameters for different bottle types.
Functions of Double Head Shrink Sleeve Labeler
  • First head and second head can operate simultaneously, with a potential production speed of up to 720 BPM with a 180mm label (under conditions where the conveyor and feeding system are compatible).
  • If the first head requires maintenance, experiences anomalies, or needs label replacement, the second head can continue production with a speed of up to 650 BPM with a 180mm label.
  • First and second heads can label different parts simultaneously and separately. For example, one head can label the bottle body, and the other one can label the bottle neck, all on the same production line.
  • When the first head is in production and the second head is in a ready state (not in production but without anomalies), if the first head experiences an issue, the second head can automatically start production without reducing production efficiency.
Shrink Sleeve Types
  • Neck Tamper Evident Banding Suitable for sealing various bottle and can openings to prevent tampering or foreign objects from entering, preserving the product's original condition and quality.
  • Full Body Over-The-Cap Sleeve Labeling Labels cover the bottle opening, body, and bottom, commonly used for sauces, condiments, and other products.
  • Full Body Shrink Sleeve Labeling Labels cover the area from the bottle opening to the bottom, often used for juices, coffee, and similar products.
  • Partial Body Shrink Sleeve Labeling Labels are positioned in the center of the bottle, a common packaging type for various bottled and canned products.
  • Full Body & Underlap Sleeve Labeling Specifically designed for packaging that requires labeling to the product's bottom, showcasing product design aesthetics and a more appealing appearance.
Packaging Applications

This shrink sleeve labeling machine is widely used in various packaging industries, including beverage packaging, dairy product packaging, bottled water packaging, pharmaceutical packaging, and more. It is suitable for containers of different sizes and shapes, including square, curved, cup-shaped, and unique bottle types.
