ES078 Series Fiber Endoscope
Request a Quote
Lens
- The diameter is only 0.78mm, 0.5mm and the standard length is 600mm. The length can be customized according to your requirements.
- Camera depth of field 2~15mm; lens field angle of 90°; eyepiece magnification 65 times; up to 20,000 pixels
- Polytetrafluoroethylene flexible hose; optical fiber transmission
- Rear portable LED flashlight with adjustable brightness
Portable display system
- 3.5-inch HD LCD screen; You can also customize various screen sizes according to your requirements.
- 2 mega-pixel high-definition micro CCD image sensor
- 1080P video resolution, clearly displaying internal inspection
- Optical adapter 32x magnification, 32G memory, controllable photo and video recording storage
Specifications
| Outer diameter | Length | Pixel | Field of view (FOV) | Depth of field (DOF) | View angle |
| 600mm or others | 10,000 pixels | 90° | 2-15mm | Forward view 0° | |
| 600mm or others | 10,000 or 20,000 pixels | 90° | 2-15mm | Forward view 0° | |
| Optional | Handheld flashlight, Desktop light source, Optical C-Mount, 2-megapixel HD industrial camera, 3.5/10.1-inch HD endoscope screen | ||||
