EVET3000 Series Veterinary Endoscope

EVET3000 Series Veterinary Endoscope
EVET3000 Series Veterinary Endoscope
EVET3000 Series Veterinary Endoscope
Request a Quote

Veterinary endoscopes are commonly used medical devices in many animal hospitals. Veterinarians can employ endoscopes for visual inspections and diagnosis when regular diagnostics, lab tests, X-rays, and ultrasounds fail to clearly diagnose animals. The endoscope can also be used for quick treatments include extracting foreign objects, gathering biopsy samples, or doing minimally invasive procedures with the use of specific accessories.

    Specifications
    Field of view (FOV) ≥140°
    Depth of field (DOF) 3-100mm
    Outer diameter of probe 8.0mm
    Outer diameter of insertion tube 8.2mm
    Inner diameter of working channel 2.0mm
    Bending angle Up 200° Down 90° Left /Right 100°
    Working length 1500-3000mm
    Illumination ≥1w/Lx
    Water delivery ≥40mL/m
    Air delivery ≥800mL/m
    Suction volume ≥250mL/m
    Waterproof rating IPX7
    Features
    • Output Interface: DVI, Y/C, CYNC, AV1, AV2
    • Resolution: 1280 * 1024
    • AWB Function: White Balance Function
    • Sharpness: 4 Level
    • Display: 10-Inch HD Screen
    • Light Unit and Control
    • SD Memory Card for Video & Image Capture
    • Color Standard: PAL
    • LED Backend light
    • LED life: ≥50000 Hours
    • Color Temperature: 5000K~6500K
    • Power Supply: 110V~240V
    • 1.14 Air Pump, Pressure Range 30kPa~80kPa
    • Adjustable Airflow: High ≥ 4L/min, Low ≥ 3L/min
