717H Motor Grader
Request a Quote
- Sing-handle electro-hydraulic controlled power-shift T/M, 6 forward&3 reverse shifts makes operation easy and convenient
- Hydraulic lock, auto lock/unlock NO-SPIN differential ensures stability
- Powerful traction deal axle load allocation provides excellent stability while cutting hard surface
- Serviceable, efficient hydraulic system enables every part to be fully used
- Box-typed frame and advanced T/M enable it to complete heavy-duty work
- A wide working range is accomplished through flexible blade suspension system and articulated frame
Consulting Products Information
Specifications of Motor Grader 717H:
Basic specification | |
Engine model | Cummins 6BTA5.9-C180 |
Rated power | 132KW@2200rpm |
Dimension(L×W×H) | 8820×2600×3420(mm) |
Operating weight(Standard) | 14500KG |
Performance specification | |
Travelling speed, forward | 6.5/11.4/14.6/24.8/30/49.2 |
Travelling speed, reverse | 6.5/14.6/30 |
Tractive force(f=0.75) | 74.6KN |
Operating specification | |
Max. steering angle of front wheels | 49° |
Max. lean angle of front wheels | 17° |
Max. oscillation angle of front axle | 16° |
Max. oscillation angle of balance box | 13° |
Frame articulation angle | 26° |
Min. turning radius using articulation | 7.3m |
Blade | |
Maximum lift above ground | 450mm |
Maximum grading depth | 535mm |
Maximum blade position angle | 90° |
Blade cutting angle | 29°~77° |
Circle reversing rotation | 360° |
Moldboard width × height | 3658×580mm |
