Vertical Pallet Conveyor
Pallet lifter for lifting and lowering of pallets
Vertical pallet conveyor is composed of a lifting device and a conveyor, allowing for the mutual transfer of pallets from the ground to a specified height. The vertical movement of this equipment is driven by a single motor synchronously on both sides of the conveying platform, ensuring the levelness of the platform, providing high synchronization and reliability in conveying. Additionally, the use of a single motor reduces the cost of the drive components and enhances the economy. After the improvement of the motor being placed at the bottom, the overall height is reduced, making it more adaptable in height-restricted areas.
Vertical pallet conveyor is used for the docking of manual carts, electric carts, AGVs, and other handling equipment with other conveying equipment.
Vertical pallet conveyor is suitable for handling various materials carried on pallets.
EV battery, automated warehouse logistics, tobacco and alcohol industry, e-commerce retail, pharmaceuticals and food, automotive and construction materials, etc.
- Utilizes roller stopper guiding.
- Conveyor surface height of 80mm.
- Four-chain lifting mechanism.
| Parameter | |
| Length mm | 1400≤L≤2800 |
| Width mm | B 1280mm |
| Effective width B mm | 820≤B≤1420 |
| Height H mm | 80mm/1000mm (Low/High) |
| Motor Brand | SEW, NORD, CPG |
| Chain Brand | ZIQIANG CHAIN, CHOHO |
| Bearing/Bearing Seat Brand | HRB/FSB, NSK/FSB, SKF/FSB, NSK/NSK |
| Color | Powder coating with all RAL colors available. |
| Nonstandard models can be customized. | |
| Product Information | ||
| Basic Information | Load Capacity | ≤1200kg |
| Conveying Speed | 12, 16, 18m/min | |
| Lifting Speed | 8m/mim | |
| Temperature | 5℃ to 45℃ | |
| Relative Humidity | ≤90% (No condensing) | |
| Roller | Roller Diameter | Ø60 |
| Roller Drive | Steel double sprocket | |
| Installation | Internal thread | |
| Drive Mode (Conveying Unit) | Drive Motor | Gear motor |
| Motor Power | 0.37, 0.55, 0.75, 1.1kW (braked motor) | |
| Motor Voltage | 380V | |
| Brake Voltage | 220V | |
| Drive Method | Chain | |
| Installation | Ground Installation | Expansion bolts |
| Ground Flatness | Level ground, error ≤5° | |
| Height Adjustment | ±10mm | |
