High Flow Membrane Filter Cartridge for Wet Process, 83 Series

High Flow Membrane Filter Cartridge for Wet Process, 83 Series
High Flow Membrane Filter Cartridge for Wet Process, 83 Series
High Flow Membrane Filter Cartridge for Wet Process, 83 Series
High Flow Membrane Filter Cartridge for Wet Process, 83 Series
Request a Quote

Optimize your wet process filtration with our high flow membrane filter cartridges. Specifically designed for flat panel display manufacturing, these cartridges offer a large filtration area and high flow rates, satisfying flow requirements of the 5th to 6th generation production lines with speed up to 120L/min.

Benefit from superior features like high flow capacity, minimal resistance, extended lifespan, and great chemical compatibility. With our high flow membrane filter cartridges, you can achieve stability in your production while effectively filtering a range of substances including acids, alkalis, and solvents.

Materials of Construction
Filter Medium Hydrophobic PTFE membrane / hydrophilic PTFE membrane / PES membrane / PP membrane
Center Rod/Housing/End Cap PP
Specifications
Length 8", 10"
Micron Rating PFL/PFLH:0.2~10μm
EPS:0.05~1.2μm
HPPV:0.5~90μm
Diameter 83mm
Max. Operating Temperature 80℃
Max. Differential Pressure 4.0 bar / 21℃ 2.4bar / 80℃
Applications
  • Super high-flow process filtration for high generation production line in the display industry
  • Substrate cleaning and filtration
  • High-pressure water filtration
  • Chemical solution filtration"
