SY-11 Pneumatic Free Fall Shock Machine
Request a Quote
The SY-11 pneumatic free fall shock machine is a newly-designed type of shock and bump test equipment. It features simple operation, convenient maintenance, and high degree of automation. The tester is suitable for all sorts of shock tests such as the conventional half-sine wave, post-peak sawtooth wave, square wave, and more.
Functions and Characteristics
- The pressure driven device has simple structure and high reliability. It produces no pollution, thus securing a clean and healthy environment.
- This pneumatic free fall shock machine can significantly improve its impact test efficiency. Its maximum collision frequency reaches 100times/min.
- It is extremely easy to realize large pulse width and small overload test.
- With high shock velocity, the shock tester adopted can substitute for a collision table. It gives higher reliability and better collision waveform when compared to a motor-driven or hydraulic drive collision table.
- The pneumatic free fall shock machine allows shock velocity to be controlled by adjusting gas pressure. It is convenient to adjust collision speed.
- This product adopts a Shock DAQ series shock control and measurement system to realize multiple optional impact modes including the manual shock, continuous shock, single shock, and the interval shock.
Main Specifications
Model | | | | | |||||||||||||||||||
Rated Load (kg) | 25 | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | |||||||||||||||
Table Size (mm) | 300x300 | 500x500 | 600x600 | 600x800 | 800x1000 | 800x1000 | 1200x1200 1000x1200 | 1200x1200 1000x1200 | |||||||||||||||
Shock Waveform | Half-sine | Postpeak Sawtooth | Half-sine | Postpeak Sawtooth | Trapezoid | Half-sine | Postpeak Sawtooth | Trapezoid | Half-sine | Postpeak Sawtooth | Trapezoid | Half-sine | Postpeak Sawtooth | Trapezoid | Half-sine | Postpeak Sawtooth | Trapezoid | Half-sine | Postpeak Sawtooth | Trapezoid | Half-sine | Postpeak Sawtooth | Trapezoid |
Shock Acceleration (m/s2) | 30-6000 | 150-1500 | 30-6000 | 150-1500 | 300-1000 | 30-6000 | 150-1500 | 300-1000 | 30-2000 | 150-600 | 300-600 | 30-1500 | 150-600 | 300-600 | 30-1500 | 150-600 | 300-600 | 30-1000 | 150-500 | 300-500 | 30-1000 | 150-500 | 300-500 |
Pulse Duration (ms) | 40-1 | 11-3 | 40-1.5 | 18-3 | 12-6 | 40-1.5 | 18-6 | 12-6 | 40-3 | 18-6 | 12-6 | 40-6 | 18-6 | 12-6 | 40-6 | 18-6 | 12-6 | 30-6 | 18-6 | 12-6 | 30-6 | 18-6 | 12-6 |
Dimension (L×W×H: mm) | 900x780x2000 | 1140x880x2120 | 1260 x 880 x 2020 | 1120x1220x2050 | 1450x1600x2450 | 1450x1350x2450 | 1950x1550x2450 | 1950x1550x2450 | |||||||||||||||
Size of Control Cabinet (mm) | 545 x 720x1335 | ||||||||||||||||||||||
Size of Pressurization Device (mm) | 300 x 300 x 850 | 400 x 400 x 850 | |||||||||||||||||||||
Weight (kg) | 1500 | 1800 | 2500 | 2600 | 3800 | 3800 | 5200 | 5200 | |||||||||||||||
Max. Bump Frequency (time/min) | 120 | 120 | 100 | 80 | 50 | 40 | 30 | 30 | |||||||||||||||
Standard | GJB150 GJB360 GJB548 GB/T2423 JJG541 MIL-STD-810F EC68-2-27 | ||||||||||||||||||||||
Remark | This product can be customized in accordance with the requirements of users. |
