Intelligent Fabric Pattern Slitting Machine
Request a Quote
Intelligent fabric pattern slitting machine is mainly used for cutting double-layer fabrics produced by double-needle bar warp knitting machines.
Features
- Multi-objective optimization design based on the servo-controlled adjustable mechanism of the blocking plate.
- Research and application of new detection methods: the use of new sensors enables the detection of pile height with an accuracy of ±0.1mm.
- Development of an automatic tensioning mechanism with a blade to ensure consistent tension requirements.
Specifications
| Working width | 100"/110" |
| Control system | Intelligent control |
| Max. batching diameter | 1524mm (60inch) |
| Fabric width | 2000mm/2300mm/2500mm/2800mm |
| Fabric thickness | 3-50mm |
| Cutting speed | 0-40m/min |
| Slitting method | Vertical slitting belt |
| Batching method | Pile up / roll |
| Main motor power | 5.5kW |
| Take-up motor power | 1.5kW |
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| 11000×6000×2500 | 66 | 3000 | 15 | |
| 11000×6300×2500 | 69.3 | 3200 | 15 |
