MIG SERIES MIG Welder, Metal Inert Gas Welding
Features
- Single phase, flux wire welding machine for flux (no gas) welding.
- This equipment features thermal protection and comes with a complete array of welding accessories.
- The MIG series welders are used to weld a variety of different materials, including steel and stainless steel.
Parameters
| Model | MIG-100 | MIG-130 | MIG-150 | MIG-175 | MIG-195 |
| Type | NO gas | Gas/NO gas | |||
| Power Voltage(v) | 230 | 230 | 230 | 230 | 230 |
| Frequency(hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Input Power(kva) | 2.5 | 3.6 | 3.7 | 5.2 | 6 |
| Fuse(a) | 10 | 13 | 16 | 16 | 16 |
| Power Factor | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 |
| Max no-load voltage output(v) | 33 | 37 | 34.2 | 35.8 | 37 |
| Current Range(a) | 50-80 | 50-120 | 60-140 | 60-160 | 60-180 |
| Duty Cycle(%) | 80@10% | 105@15% | 115@15% | 140@15% | 140@20% |
| Adjustment Positions | 4 | 4 | 4 | 4 | 4 |
| Insulation Class | H | H | H | H | H |
| Protection Class | IP21s | IP21s | IP21s | IP21s | IP21s |
| Measurement(mm) | 450*240*410 | 450*240*410 | 595*340*410 | 595*340*410 | 595*340*410 |
| Welding wire dia(mm) | 0.6-0.9 | 0.6-0.9 | 0.6-1.0 | 0.6-1.0 | 0.6-1.0 |
| Weight(kgs) | 17 | 18.5 | 35 | 37 | 38 |
| Cod.(no) | 880017 | 880018 | 880019 | 870020 | 870021 |
