MIG SERIES MIG Welder, Metal Inert Gas Welding
Features
- This MIG welder is a portable single-phase, fan-cooling, wire welding machine.
- It is designed for continuous welding and spot welding.
- This equipment features electric control for the spot welding time.
- The MIG welder is able to weld a variety of materials, including steel and stainless steel.
- This equipment come with a complete line of MIG-MAG welding accessories.
Parameters
| Model | MIG-200 | MIG-250 | MIG-280 |
| Power Voltage(v) | 230 | 230 | 230 |
| Frequency(hz) | 50/60 | 50/60 | 50/60 |
| Input Power(kva) | 7 | 7.7 | 9.5 |
| Fuse(a) | 20 | 25 | 30 |
| Power Factor | 0.9 | 0.9 | 0.9 |
| Max No-load voltage In Dc (v) | 38 | 40 | 42 |
| Current Range Input Dc(a) | 50-200 | 50-240 | 50-270 |
| Duty Cycle( %) | 180@15% | 200@15% | 230@20% |
| Welding Wire Diameter(mm) | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 |
| Insulation Class | H | H | H |
| Measurement(mm) | 860*425*570 | 860*425*570 | 860*425*570 |
| Weight(kgs) | 53 | 74 | 75 |
| Cod.(no) | 870023 | 870024 | 870025 |
