MIG-I SERIES MIG Welder
Request a Quote
Welding machine manufacturerSince 1988
MIG-I SERIES MIG Welder, Metal Inert Gas Welding
Features
- The MIG-I series MIG welder is suitable for welding plates over 0.8mm.
- It features IGBT technology and a high duty cycle.
- This MIG welder is easy to operate with a fast wire feeding speed.
- The MIG-I series MIG welder features an automatic compensation function for input voltage fluctuation.
- This equipment is ideal for welding carbon steel, alloy steel, and other steel materials.
- With very little spatter, it features an excellent welding appearance.
Parameters
| Model | MIG-200I | MIG-250I | MIG-280I | MIG-200S | MIG-250S |
| Power Voltage(v) | 220 | 380 | 380 | 220 | 380 |
| Input Voltage Frequency(hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Output Current Range(a) | 50-200 | 50-250 | 50-280 | 50-200 | 50-250 |
| No-load voltage (v) | 52 | 53 | 53 | 52 | 53 |
| Insulation Class | F | F | F | F | F |
| Efficiency(%) | 85 | 85 | 85 | 85 | 85 |
| Duty Cycle( %) | 60 | 60 | 60 | 60 | 60 |
| Wire Diameter(mm) | 0.8-1.0 | 0.8-1.0 | 0.8-1.2 | 0.8-1.0 | 0.8-1.0 |
| Weight(kg) | 45 | 45 | 45 | 24 | 24 |
| Measurement(mm) | 860*450*685 | 860*450*685 | 860*450*685 | 630*390*540 | 630*390*540 |
| Usable Electrode(mm) | / | / | / | 1.6-4.0 | 1.6-4.0 |
| Cod.(no) | 870013 | 870014 | 870015 | 870010 | 870011 |
