Rotary Capping Machine, SC-R250
Request a Quote
The SC-R250 rotary capping machine is designed to automatically feed, sort and apply screw caps to various containers, including round bottles, square bottles and oval bottles. It is an ideal bottle capper machine for use in pharmaceutical, supplement, candy and household chemical, food and beverage industries.
Features
- Centrifugal cap orientation, CMOS laser sensor for judging front or back of the cap, air blow-off rejection without damaging caps;
- Tool-less changeovers for timing screws, star wheels and capping heads, locating pin for precise positioning, less than 30 minutes for changeover;
- Detection of upside down bottles, protection against overload to the screw;
- Pneumatic three-jaw gripper, automatic centering without damaging caps;
- Exclusive permanent magnet clutch torque limiter, torque adjustment and precise control of cap torque;
- Motorized height adjustment to accommodate various bottle sizes;
- Detection and rejection of upside down caps, caps with no aluminum foil, loosen caps and deformed caps;
- Transparent tempered glass door, stainless steel and aluminum construction, ensuring operation safety and easy cleaning;
- Human-machine operation system with 10-inch screen;
Technical Specifications
| Overall dimensions | 1250mm (L)×1350mm (W)×2250mm(H) (main machine) | |
| Weight | 1600kg | |
| Max. capacity | 250 bottles/min | |
| Applicable specification | Bottle height: 45-200mm | |
| Bottle diameter: 020-100mm | ||
| Cap height: 10-30mm | ||
| Cap diameter: 020-60mm | ||
| Number of capping head | 10 | |
| Unscrambling speed | Max. 350 caps/min. | |
| Detection and rejection | Removal of misaligned cap and caps with no aluminum foil (standard) Removal of upside down aluminum foil (optional) | |
| Breakage rate | < 0.001% | |
| Screw-on cap pass rate | ≥99.98% | |
| Noise level | ≤70dB | |
| Electric and air requirements | Main Power Supply | AC220V-50HZ-3 wire |
| Installed capacity | 3.0kW | |
| Compressed air | Quick change adapter: 10mm 200L/min(0.6MPa-0.8MPa) | |
