Automatic Cable Coiling and Wrapping Machine

Automatic Cable Coiling and Wrapping Machine
Automatic Cable Coiling and Wrapping Machine
Automatic Cable Coiling and Wrapping Machine
Request a Quote

Fully automatic cable coil packaging machine

Upgrade your cable packaging process with the Automatic Cable Coiling and Wrapping Machine.

Our fully automatic packaging machine efficiently coils the cable and wraps it with packaging film in a seamless process. It boasts a high production speed, reaching up to 260 m/min, ensuring efficient and timely packaging.

Features
  • Automatic Arm Adjustment: Our automatic packaging machine automatically adjusts the cable holding arm, eliminating the need for manual adjustments.
  • Automatic Labeling: The automatic packaging machine features automatic label application, eliminating the need for manual label placement and ensuring safety and convenience.
  • Optional Automatic Stacking System: Our automatic packaging machine can be equipped with an automatic stacking system for further efficiency.
  • Error Detection and Alert: The system automatically detects errors and alerts the operator, ensuring prompt resolution.
  • Labor Savings and Production Expansion: Our cable packaging machine optimizes labor usage, expands production capacity, and boosts industrial automation.
Specifications
Model
TP 460
TP 600
Applicable wire section 4 - 12 mm² 5 - 18 mm²
Production speed 260 m/min 200 m/min
Outer diameter of coils Ø240 - 460 mm Ø320 - 600 mm
Inner diameter of coils Ø170 - 220 mm Ø200 - 300 mm
Height of coils 60 - 100 mm 80 - 160 mm
Packing material PVC PVE
Automatic stacking and palletizing system Optional Optional
