Automatic Cable Spooling and Coiling Machine
Request a Quote
Microcomputer controlled packaging machine for cables with or without reels
Optimize your cable packaging process with the Automatic Cable Spooling and Coiling Machine.
Our microcomputer-controlled packaging machine is designed for cable packaging, capable of coiling cables with or without reels. Additionally, it can be equipped with a heat shrink film or wrapping machine for further heat shrink packaging.
Features
- Automatic Spooling and Wrapping: After cable retrieval, our packaging machine automatically spools and wraps the cable for packaging.
- Adjustable Coil Height: Our packaging machine allows for easy adjustment of the coil height, automatically aligning to the desired parameters.
- Automated Reel Handling: Our microcomputer-controlled packaging machine handles the input, positioning, and output of cable reels automatically.
- High Automation and Versatile Functionality: Our microcomputer-controlled packaging machine boasts high automation levels, comprehensive functionality, stable performance, and wide applicability.
Specifications
| Model | Coiling Method | Outer Diameter (mm) | Height (mm) | Inner Diameter (mm) | Wire Diameter (mm) | Packing Material | Line Speed (1 coil = 100 m) |
YP200 | Spooling | 150 - 200 | 160 - 240 | 80 - 105 | 2 - 4 | PVC, PE | 1.5 - 2 coils/min |
| Coiling | 250 - 300 | 90 - 130 | 140 - 160 | 2 - 4 | |||
YP300 | Spooling | 150 - 300 | 160 - 240 | 80 - 105 | 4 - 8 | ||
| Coiling | 250 - 400 | 90 - 130 | 140 - 160 | 4 - 8 |
