High-temperature Oil-operated Mold Temperature Control up to 300/350 °C

High-temperature Oil-operated Mold Temperature Control up to 300/350 °C
High-temperature Oil-operated Mold Temperature Control up to 300/350 °C
High-temperature Oil-operated Mold Temperature Control up to 300/350 °C
High-temperature Oil-operated Mold Temperature Control up to 300/350 °C
Request a Quote

This temperature control unit is suitable for high temperature applications in plastic calendering equipment, printing equipment, and injection molds where high temperature control is highly required.

Features:
  • Microprocessor PID, easy to operate
  • Automatic air exhausting function
  • Oil temperature display
Specification:
Model Unit OTH-20 OGH-20 OTH-30 OGH-30 OTH-50 OGH-50 OTH-75 OGH-75 OTH-100 OGH-100 OTH-150 OGH-150
Temperature control range OTH:60℃-300℃ OGH:60℃-350℃
Temperature control accuracy ±1
Power supply KW 12/18 18/24 24/36 36/48 48/72 72/96
Pump power KW 1.5 2.2 3.75 5.5 7.5 11
Max. flow L/MIN 130 165 205 330 665 1000
Max. pressure KG/CM2² 2.2 2.5 3.2 3.8 4.3 3.8
Max. power consumption KW/H 13.6/19.7 20.4/26.4 28.1/40 41.9/54 56/80.5 84/108
Cooling water pipe INCH 1/2" 1/2" 1/2" 1/2" 1/2" 1/2"
Circulating water pipe INCH 1 1-1/4 1-1/2 2 2 2
