Cylindrical Lens Mount
Request a Quote
The cylindrical lens mount can be used in laser processing, optical experiments and automatic measurement and testing and other places that require to assemble cylindrical lens.
- WN01CL
- WN02CL
| Model | WN01CL |
| Two-dimensional tilt adjustment range | ±4° |
| Rotating adjustment range | ±5° |
| Mounting length | 50-50.8 mm |
| Mounting width | 60. 5mm |
- The cylindrical lens can be adjusted around two-dimensional orthogonal and coplanar axes.
- The cylindrical lens can be rotated around the light axis.
- Two types of plano-convex or plano-concave cylindrical mirrors can be mounted. The cylindrical mirror can be placed horizontally or vertically.
| Model | WN02CL |
| Mounting size | 6.4x25 |
| 12.7x25 | |
| Weight | 0.05 kg |
- The lens is clamped by tightening screw.
- Different sizes of cylindrical lens can be mounted.
- Teflon made gasket can protect lenses effectively.
