Integrated Vacuum Insulated Boxes
Request a Quote
Our integrated vacuum insulated box can target customers of varying needs in the cold chain transportation of medicine, fresh health product, food, etc. Various accessories is also available to suit different applications, such as insulating material, phase change material (PCM) cold pack, temperature indicator, Bluetooth printer, non-woven cooler bag, insulated box liner and so on.
Features
- Long-term performance of thermal insulation;
- Cost-Effective: using less phase change material (PCM) cold pack under the same thermal insulation requirements;
- Stable and enduring thermal protection based on high performance vacuum insulation panel;
- Energy-saving and environment-friendly: Using recyclable and reused material;
- In compliance with GSP Regulations;
- Nearly all sizes available;
Specifications
- Insulation time: 24h-120h;
- Operational environment: -30℃~80℃;
- Temperature range (optional): 10~20℃, 2~8℃, -1~3℃, -15~-25℃;
Parameters
| Box Type | Internal size | External size | Internal volume | Box weight | Box Thickness | Duration time（2~8℃） | PCM Weight |
| STYT-V16 | 380*310*140 | 430*360*195 | 16L | 1.3kg | 25mm | 24~72h | 1.5~4.5kg |
| STYT-V50 | 368*368*368 | 468*468*468 | 50L | 4.8kg | 50mm | 72~120 | 8.7~11kg |
