YX25-765-1026 Roof Panel Roll Forming Machine
Request a Quote
YX25-765-1026 roof panel roll forming machine is a state-of-the-art equipment for rollforming 0.4-0.8mm thick roofing sheets. With a production speed of 15m/min, the metal roofing machine roll forms panels with an effective cover width of 765mm and 1026mm.
Samples
Profiles
| Model | YX24-765-1026 |
| Dimension | 8000*1500*1500mm |
| Motor Power | 7.5kW |
| Hydraulic Power | 2.2kW |
| Forming Steps | 18steps |
| Forming Speed | 10-15m/min |
| Voltage | 380V/50HZ/3PH |
| Material Thickness | 0.4-0.8mm |
| Rib Height of Roofing | 24mm |
| Effective Cover Width | 765mm,1026mm |
| Feeding Material Width | 914mm,1200mm,1219mm |
| Control System | PLC Control |
-
-
Cutter is manufactured by Cr12 mold steel, with HRC58-60 heat treatment for high quality and long service life.
-
-
Roller is made of high quality 45# steel with CNC lathes.
Hard chrome plating is available for long service life.
Body frame is welded with 400# H bean.
-
-
PLC Control System can be chosen from Schneider, Siemens, and Delta
-
-
Hydraulic pre-cutter can be chosen for operation to save labor cost.
- Main machine
- 5 tons manual uncoiler
- Hydraulic forming cutter (Material: Cr12Mov with heat treatment)
- Hydraulic System
- PLC computer controlling system with touch screen (Brand: Schneider)
- Manual Pre-cutter or Hydraulic Pre-cutter
- Tools
- Operation Manual
