Diesel Portable Screw Air Compressor, KSCY
Request a Quote
- Working pressure: 8(116) - 20(300) Bar (Psi)
- Free air delivery: 6(220) - 21(750) m³/min (cfm)
- Power: 55 (75) - 240(310) kW (HP)
KAISHAN is a reputable manufacturer of screw air compressors in the domestic market. Our KSCY series portable screw air compressors are particularly praised by customers worldwide. Please contact us if you have any questions about our screw air compressors.
| Model | |||||||||||||||
| Air Compressor | |||||||||||||||
| Free air delivery | m³/min(cfm) | 6(220) | 9(330) | 12(425) | 11(400) | 15(550) | 15(550) | 17(580) | 16(570) | 15(560) | 21(750) | ||||
| Discharge pressure | Bar (Psi) | 8(116) | 8(116) | 10(145) | 14.5(212) | 13(190) | 14.5(210) | 17(250) | 12(174) | 15(218) | 20(300) | ||||
| Fuel tank capacity | L | 30 | 30 | 40 | |||||||||||
| Compression stage | 1 | ||||||||||||||
| Diesel Engine | |||||||||||||||
| Manufacturer | Xichai | Yuchai | Yuchai | Yuchai/Cummins | Yuchai | Yuchai/Cummins | Yuchai /Cummins | Yuchai/Cummins | Yuchai | Yuchai | |||||
| Model | 75HP(55) | 120HP | 160HP | 160HP | 180HP | 180HP | 6CTA8.3-C260 | 180HP | 220HP | 310HP | |||||
| Rotating speed under full load | r/min | 2100 | 2100 | 2100 | 2100 | 2500 | 2200 | 2200 | 2200 | 3000 | 2200 | ||||
| Unloaded rotating speed | r/min | 1400 | 1400 | 1400 | 1400 | 1400 | 1500 | 1500 | 1500 | 1500 | 1500 | ||||
| Rated power | HP(kW) | 75HP(55) | 110(150) | 160(118) | 160(118) | 180(132) | 180(132) | 260(194) | 180(132) | 220(162) | 310(240) | ||||
| Capacity | L | 6.8 | 6.8 | 6.8 | 6.8 | 5.9 | 8.3 | 8.3 | 8.3 | 8.3 | 8.3 | ||||
| Fuel tank capacity | L | 130 | 130 | 130 | 130 | 195 | 300 | 300 | 300 | 300 | 300 | ||||
| Electric system voltage | V | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | ||||
| Entire Air Compressor | |||||||||||||||
| Sound | ±3dB(A) | 80 | 80 | 82 | 82 | 82 | 82 | 82 | 82 | ||||||
| Weight | kg | 2200 | 2200 | 2400 | 3200 | 3200 | 3200 | 3200 | 3200 | ||||||
| Length | mm | 3000 | 3650 | 3000 | 3600 | 3600 | 3600 | 3600 | 3600 | ||||||
| Width | mm | 1880 | 1880 | 1520 | 1800 | 1800 | 1800 | 1800 | 1800 | ||||||
| Height | mm | 2060 | 2060 | 2200 | 2450 | 2450 | 2450 | 2450 | 2450 | ||||||
| Outlet valve | G11/2×1,G3/4×1 | G2×1, G3/4×1 | |||||||||||||
