SBCF Vacuum Forming Machine
Features
1. The SBCF vacuum forming machine is smartly designed through the integration of mechanism, electricity, and pneumatics.
2. It is the first plastic vacuum forming machine in China installed with PLC system, touch screen programming system, and digital voltmeter temperature control system.
3. This high-efficiency plastic forming machine is capable of completing material feeding, heating, forming, cooling, demoulding and cutting, at one stroke.
4. The imported parts are conducive to the stable performance and simple operation of the plastic processing machinery.
Applications
The vacuum forming machine is extensively used in plastic sheet forming, such as PS, HIPS, PVC, PET, PP, and flocking, for manufacturing various kinds of trays and linings for materials packaging, including medical agentia, oral liquid, mobile phone, biscuit, disposal tableware, and some others.
| Model | SBCF-700/1200A | SBCF-700/1200B |
| Forming Length | 760-1200mm | 760-1200mm |
| Forming Width | 500-700mm | 500-700mm |
| Forming Height | <165mm | <165mm |
| Production Capacity (times/hour) | 60-720 cycles/h | 60-720 cycles/h |
| Power Consumption of Electric Heater (kW) | 24kW | 24kW (max.) 18kW (min.) |
| Power Consumption of Vacuum Pump (kW) | 3kW | 3kW |
| Pumping Rate (m³/h) | 100m³/h | 100m³/h |
| Power Consumption of Air Compressor (kW) | 7.5kW | 7.5kW |
| Gas Displacement (m³/min) | 0.9m³/min | 0.9m³/min |
| Voltage (V/Hz) | 380/220V 50Hz | 380/220V 50Hz |
| Overall Dimension (mm) | 7950×1450×2550mm | 7950×1450×2550mm |
| Weight (kg) | 3000kg | 3500kg |
