Three Dimensional Adjustment System

Three Dimensional Adjustment System
Request a Quote
7-PMC200
Integrated multi-axis positioning system
Features
  • Versatile three-dimensional adjustment

    primarily designed for adjusting instruments in three dimensions, including vertical lifting and horizontal translation in two dimensions. Capable of bearing loads up to 100kg.

  • Vertical lifting

    offers a ±100mm travel range with a worm lifting structure and cylindrical linear guide support. Ensures stable and substantial load-bearing capabilities with no return clearance and high-resolution transmission (1 micron). Powered by a stepper motor for precise positioning.

  • Horizontal translation in two dimensions

    provides a ±50mm travel range with linear sliding guide and ball screw drive. Features a reducer for both coarse and fine adjustments, with the option for manual control via a hand wheel. Offers smooth speed feed and high resolution (1 micron) for optimal user experience.

  • Sturdy bracket

    built with high load-bearing capacity and easy implementation. Ensures reliable leveling and boasts a stable and aesthetically pleasing design.

  • Customizable adjustment rack

    tailorable to specific requirements with various technical parameters. Suitable for diverse applications, accommodating different component sizes and driving modes.
