Features

The frame of conventional hydraulic press brake is entirely welded with steel plates, and tempered in order to relieve stress and improve the strength and durability of the machine.
A hydraulic top-drive, stepless pressure adjustment, and high-quality sealing rings imported from overseas guarantee the reliability of the machine tool.
The mechanical synchronization mechanism with upper and lower complex compensation structures are designed to improve the machining precision of workpieces. (160 tons and below uses a compensation structure under the worktable)
The slide stroke adjustment and back gauge positioning adjustment employ an electric fast adjustment and manual micro adjustment, and are equipped with a digital display.
Inch, single, continuous operation modes are designed for the press brake in order to reverse and maintain time through the control of time relays.
The machine tool is set with safety barrier and device for cutting off the electricity when opening the door in order to ensure operation safety. (40 tons back side and 200 tons above without safety barrier)

Parameters

Type		WC67Y-40/2000	WC67Y-40/2500	WC67Y-63/2500	WC67Y-80/2500	WC67Y-80/3200	WC67Y-80/4000	WC67Y-100/2500	WC67Y-100/3200	WC67Y-100/4000	WC67Y-125/2500	WC67Y-125/3200	WC67Y-160/2500	WC67Y-160/3200	WC67Y-160/4000	WC67Y-160/6000	WC67Y-200/3200	WC67Y-200/4000	WC67Y-200/6000	WC67Y-250/3200	WC67Y-250/4200	WC67Y-250/5000	WC67Y-250/6000	WC67Y-300/4000	WC67Y-300/5000	WC67Y-300/6000	WC67Y-400/4000	WC67Y-400/6000	WC67Y-500/4000	WC67Y-500/6000
Nominal force	kN	400	400	630	800	800	800	1000	1000	1000	1250	1250	1600	1600	1600	1600	2000	2000	2000	2500	2500	2500	2500	3000	3000	3000	4000	4000	5000	5000
Worktable length	mm	2000	2500	2500	2500	3200	4000	2500	3200	4000	2500	3200	2500	3200	4000	6000	3200	4000	6000	3200	4200	5000	6000	4000	5000	6000	4000	6000	4000	6000
Column spacing	mm	1650	2000	2000	1990	2600	3350	1850	2550	3350	1850	2550	1950	2540	3140	4800	2550	3260	4800	2540	3140	4000	5000	2900	3900	4900	3140	5000	3050	4760
Throat depth	mm	200	200	250	280	280	280	320	320	320	320	320	330	330	330	330	350	350	350	400	400	400	400	400	400	400	400	400	400	400
Slide stroke	mm	100	100	100	100	100	100	130	130	130	130	130	200	200	200	200	200	200	200	250	250	250	250	250	250	250	320	320	320	320
Stroke adjustment	mm	80	80	80	80	80	80	100	100	100	100	100	150	150	150	150	150	150	150	180	180	180	180	180	180	180	220	220	220	220
Max. open height	mm	330	330	340	360	360	360	390	390	390	390	390	465	465	465	465	450	450	450	500	500	500	500	535	535	535	600	600	630	630
Number of strokes	min-1	≥11	≥11	≥10	≥10	≥10	≥10	≥10	≥10	≥10	≥10	≥10	≥6	≥6	≥6	≥6	≥3	≥3	≥6	≥6	≥3	≥3	≥3	≥3	≥3	≥3	≥2.5	≥2.5	≥2.5	≥2.5
Main motor power	kW	4	4	5.5	7.5	7.5	7.5	7.5	7.5	7.5	7.5	7.5	11	11	11	11	15	15	15	18.5	18.5	18.5	18.5	22	22	22	37	37	37	37
Net weight	kg	2663	3075	4540	4700	6080	7620	5880	7120	8240	6000	7200	8800	9620	11060	18500	11340	13300	23000	12080	15220	17000	18500	19700	24400	29200	29500	41100	42000	51000
Outline size (L×W×H)	mm	2210×1100×2240	2560×1200×2240	2680×1540×2220	2690×1530×2300	3410×1550×2300	4210×1550×2300	2680×1570×2400	3380×1570×2400	4180×1570×2400	2680×1570×2400	3380×1570×2400	2790×1830×2550	3400×1830×2550	4260×1830×2550	6140×1900×2960	3340×1855×2745	4110×1810×2745	6120×2315×2900	3310×1970×2915	4310×1950×2995	5120×2210×2980	6120×2210×2980	4150×1950×3115	5150×1950×3115	6120×1950×3520	4130×2625×3700	6150×3250×3900	4200×4115×4760	6200×4115×4760
