MRVS Series Speed Sensor

Request a Quote

View All: http://solution-sensor.com/4-4-mrvs-series-speed-sensor.html

The MRVS speed sensor is engineered to accurately detect the rotational speed and position (teeth and slots) of gears made from ferromagnetic materials. Encased in a durable metallic housing, this sensor employs advanced thin-film magnetoresistive technology. As the gear rotates, variations in the magnetic field alter the electrical resistance of the magnetoresistive element, providing precise detection of gear position and speed.

Features

Wide rotation speed detection range, up to 200,000 RPM
Durable metallic or plastic housing options available
Consistent signal amplitude independent of rotational speed
Built-in biasing magnet ensures precise sensing
Specifically designed for reliable performance in harsh environments.
Operating temperature customizable upon client request, up to 125℃

Applications

High-speed and zero-speed detection applications
Precision position detection systems
Reliable rotation detection in industrial equipment
Accurate angular encoder measurement
Linear position monitoring solutions
Precision PCB hole drilling equipment
Computerized flat knitting machines for accurate operational control

Technical Specifications

Model	MRVS-08
Maximum Power Supply V max	10 VDC
Nominal Power Supply	5 VDC
Total Resistance R1-3 (δ=0.1, I≤mA, t=25°C)	900-1600Ω
Center Symmetry M=100% (R1-2-R2-3)/R1-2 (δ=0.1)	≤10%
Offset Voltage(at Vin and δ=0.1)	≤130mV
Open Circuit Output Voltage Vout pp (at Vin and δ=0.15mm)	≥900mV
Cut-off Frequency	>20kHz
Operating Temperature*	-30 to 70℃
Storage Temperature	-40 to 85℃
Electrical Terminal	red wire: power
	black wire: common
	white wire: output signal

*Operating temperature can be customizable up to 125℃ upon client request.
