630A Backhoe Loader

Request a Quote

View All: http://sinomachhiglobal.com/4backhoe_loader_2.html

Features of Backhoe Loader 630A:

Equipped with WD DETUZ engine
4 forward & 4 reverse synchromesh mechanical shift transmission
Combined seal cylinder obtains high seal performance and more reliability
Improved loader and backhoe performance

Consulting Products Information

CARRARO wet type rear axle with multi-disc brake& CARRARO front axle
New-type cab with more space, increases comfort and visibility
With 2 wheel driving or 4 wheel driving for option

Specifications of Backhoe Loader 630A:

Model	630A
Diesel Engine	WEICHAI WP4.1G95E211
	Cummins 4BTA3.9-C110
	WEICHAI WP4.1G100E311
Front Type	12.5-16NHS-12PR(4WD)/11L-16F3-12PR(2WD)
Rear Type	19.5L-24R4-12PR
Rated Power	70/82/74kW
Rated Speed	2200rpm
Rated Loading bucket capacity	1m³
Rated load	1700kg
Max.dumping reach	845mm
Max.dumping clearance	2714mm
Max. loading breakout force	＞60kN
Rated digging bucket capacity	0.3m³
Max. digging depth	4405mm
Max. digging force	50±10%kN
Max. digging radius	5481mm
Max. dumping height	3737mm
Hydraulic system	110L
Fuel tank	151L
Transmission	18.5L

Besides the 630A backhoe loader, Sinomach have many other kinds of heavy equipment and engineering vehicle for sale.
Sinomach as an experienced heavy equipment company in China, is making construction equipment for road construction and building construction, as a leading manufacturer in heavy equipment industry.
