YD-H1800R5

• Our UV hybrid printer, a versatile machine that effortlessly blends the capabilities of a UV flatbed and roll-to-roll printer. This means you can print on both hard and flexible materials easily.
• With a maximum print width of 1800mm, this printing equipment fits into smaller spaces while delivering excellent performance.
• Depending on your needs, you can choose either the Ricoh Gen5/GEN6 or the Kyocera KJ4A printhead.
• Our UV printing systems use eco-friendly UV ink for full-color printing, including options like CMYK LcLm, white ink, or varnish.
• Thanks to the LED UV curing system, you get high-resolution prints at 600*2400dpi quickly.

This small-format UV hybrid printer opens up a world of creative and productive possibilities. Its versatile design blends flatbed and roll-to-roll capabilities, perfect for individual customization and mass production alike. Equipped with a Ricoh Gen5 printhead (Ricoh GEN6 and Kyocera KJ4A options available), this printing equipment promises remarkable speed and high resolution with every project. With this setup, the UV hybrid printing equipment is capable of printing a wide color range including CMYK, LcLm plus white and varnish, allowing for special varnish effects. This makes the YD-H1800R5 particularly great for both unique, personalized projects and large-scale production runs. Plus, it's designed to be user-friendly, easily managed through a computer for efficient and consistent operation.

• Decoration: Ideal for printing on ceramics, ceilings, windows, and doors.
• Advertising: Produces eye-catching billboards, bulletin boards, and photos.
• Packaging: Perfect for creating unique boxes, cartons, and more with special appearances.

• Seamless mesh belt
  Equipped with a polyester belt ensures flawless printing results, even on delicate materials like thin PVC film. Eliminate marks for a professional finish.
• Precision lead rail
  The high-quality HIWIN (Taiwan) lead rail guarantees stable, quiet printing operation. It's easy to maintain and offers a long lifespan of up to 10 years in standard working conditions.
• Durable IGUS towline (Germany)
  This towline protects wiring from wear and tear during high-speed printing, extending the printer's lifespan. Enjoy reliable long-term performance.
• White ink circulation and stirring
  White ink tends to settle, affecting color quality and potentially clogging the printhead. This system automatically circulates white ink and stirs it to prevent sediment buildup, ensuring consistent results.
• Automatic height measurement
  This device precisely measures the distance between the printhead and the material for optimal print quality. Save time by eliminating manual measurements and prevent errors that could damage the printer.
• Adjustable feed and take-up
  Torque motors control both feeding and take-up, allowing you to adjust tension based on material thickness. Ensure perfect print quality across various materials with precise settings.
• Ink cartridge thermostat
  The ideal printhead temperature is 45-50°C. This thermostat maintains that temperature, even in cold weather, so your printer is always ready to work. A display shows the current ink cartridge temperature.
• Anti-static function
  Static electricity on materials can cause ink splatter, ruining your print. The anti-static bar removes static charges for the best possible print quality.
• Dual Negative Pressure
  Separate negative pressure systems for white and color inks allow you to fine-tune the viscosity and gravity settings for each. Achieve optimal results with both types of ink.
